ACS800-01-0100-3+P901 ABB Variable Frequency Inverter 50/60 Hz 3 X 230V AC

ACS800-01-0100-3+P901 Description

ACS800-01-0100-3+P901 Key Features

• Advanced Direct Torque Control (DTC): Provides unparalleled precision in controlling motor speed and torque with exceptional dynamic response, operating effectively without motor feedback devices.
• High Power Capacity: Delivers a rated continuous output power of 90 kW and a maximum continuous output current of 166 A, suitable for medium to high-power motor applications.
• Flexible Load Ratings: Supports multiple operational modes: 55 kW (heavy-duty/overload), 75 kW (light-overload), and 90 kW (normal/constant torque), adapting to diverse application demands.
• Integrated Components: Comes equipped with built-in EMC filters, DC link chokes, and a brake chopper as standard, reducing the need for external components and simplifying installation.
• Comprehensive Protection: Features full electronic protection including overcurrent, overvoltage, undervoltage, overtemperature, phase loss, and short-circuit protection for both the drive and motor.
• Wide Voltage Compatibility: Accepts a broad three-phase input voltage range (380-415 V AC) and is compatible with global industrial power standards.
• Robust Enclosure: IP21 protected enclosure, providing excellent protection against solid objects and dripping water, ideal for standard industrial control cabinets.
• User-Friendly Interface: Includes an intuitive control panel with a graphical display for easy parameter setup, monitoring, and diagnostics.
• Seamless Communication: Supports a comprehensive suite of industrial fieldbus protocols for seamless integration into modern automation networks.
• High Ambient Performance: Designed to operate reliably at full load within a wide temperature range, ensuring stability in challenging plant conditions.
• Compact Wall-Mount Design: Space-optimized R6 frame size for efficient wall mounting, maximizing cabinet space utilization.
• Energy Optimization: Built-in energy-saving functions and high-efficiency operation to reduce power consumption and operational costs.
• Encoder Compatibility: Offers support for encoder feedback interfaces for applications requiring ultra-high precision speed control.

ACS800-01-0100-3+P901 Materials & Applications

Materials

• Housing: Rugged, coated steel chassis and flame-retardant plastic front panel, engineered for structural rigidity and durability in industrial environments.
• Power Circuitry: High-grade, thermally efficient PCB assemblies with heavy copper conductors, designed to handle high currents and dissipate heat effectively.
• Semiconductors: Premium-grade, industrial power IGBTs (Insulated Gate Bipolar Transistors) ensuring high switching efficiency and long service life.
• Cooling System: Optimized heatsink design with high thermal conductivity and low-noise cooling fans for efficient, maintenance-friendly thermal management.
• Terminals: Nickel-plated, heavy-duty screw terminals ensuring secure, corrosion-resistant electrical connections for power and control wiring.
• Internal Shielding: Integrated metal shielding and EMI/RFI suppression components ensuring compliance with strict EMC standards.

Typical Applications

• Pulp & Paper Industry: Control for paper machines, pumps, fans, and conveyors.
• Metals Processing: Reliable control for rolling mills, extruders, and material handling equipment.
• Mining & Cement: Operation of crushers, mills, kilns, and large ventilation systems.
• Oil & Gas: Drive control for pumps, compressors, and offshore platform machinery.
• Chemical & Pharmaceutical: Precise control for mixers, agitators, and reactor drives.
• Power Generation: Control of boiler feed pumps, cooling fans, and auxiliary systems.
• Water & Wastewater: Efficient control for large water pumps, blowers, and treatment processes.
• General Manufacturing: Machine tools, conveyor systems, and various heavy machinery.

ACS800-01-0100-3+P901 Important Parameters
