330103-00-10-05-02-00 Bently Nevada Pressure Temperature Transmitter -14.7 To 150 PSIG
Price:
Contact
MOQ:
1
Delivery Time:
3-5DAYS
Brand:
Bently Nevada
Product Description
330103-00-10-05-02-00 Bently Nevada Pressure Temperature Transmitter -14.7 To 150 PSIG
330103-00-10-05-02-00 Description
This precision non-contact eddy current proximity probe adopts high-frequency electromagnetic induction principle, specially designed for dynamic vibration, radial displacement and shaft position monitoring of large-scale rotating machinery. It matches supporting extension cables and signal conditioning modules to output linear analog voltage signals proportional to the gap between probe tip and metal measured surface. Featuring stable linearity, high anti-interference performance and wide environmental adaptability, it meets API standard requirements for safety protection and condition monitoring of critical rotating equipment in heavy industry.
330103-00-10-05-02-00 Key Features
- Non-contact measurement, no mechanical wear, long stable service life
- 8mm probe diameter, optimal linear measuring range for shaft vibration detection
- High linear accuracy & low drift, accurately capture static displacement and high-frequency dynamic vibration signals
- Wide temperature resistance, adaptable to high-temperature and harsh industrial working conditions
- Integrated sealed structure, dustproof, moisture-proof and pressure-resistant sealing performance
- Standard coaxial quick connector, convenient wiring, maintenance and component interchangeability
- Excellent electromagnetic shielding, effectively resist on-site strong electromagnetic interference
- Compliant with international machinery protection specifications, reliable overspeed & vibration alarm linkage
- Low signal delay, fast response, real-time tracking high-speed shaft operation status
- Compatible with matching cable and conditioning system, plug-and-play without repeated calibration
330103-00-10-05-02-00 Materials & Applications
Materials
- Probe shell: High-strength corrosion-resistant 303/304 stainless steel, high structural stability and pressure resistance
- Probe tip: High-temperature resistant flame-retardant PPS engineering plastic, insulation and aging resistance
- Sealing ring: Fluororubber O-ring, high temperature resistance, oil resistance and long sealing life
- Internal coil: High-precision enameled copper wire, stable high-frequency oscillation performance
- Cable sheath: Industrial wear-resistant shielded cable, anti-interference and bending resistance
- Connector: Gold-plated coaxial ClickLoc connector, low contact resistance and corrosion resistance
Typical Applications
- Power generation: Steam turbines, gas turbines, generator shaft vibration and eccentricity monitoring
- Petrochemical: Centrifugal pumps, compressors, fans, rotating shaft displacement & vibration protection
- Metallurgy & mining: Large rolling mills, blower units, critical rotating equipment health monitoring
- Energy industry: Turbine machinery shaft position, axial displacement and fault early warning
- General heavy industry: High-speed rotating machinery clearance detection, key phase signal collection
- Machinery maintenance: Predictive maintenance, fault diagnosis and safety interlock protection of rotary equipment
330103-00-10-05-02-00 Important Parameters
| Parameter | Specification |
|---|---|
| Model Number | 330103-00-10-05-02-00 |
| Probe Type | 8mm Eddy Current Non-contact Proximity Sensor |
| Thread Specification | M10×1 |
| Effective Linear Range | 0.25–2.3 mm |
| Sensitivity | 7.87 V/mm |
| Cable Length | 1.0 m |
| Working Frequency Response | 0–10 kHz |
| Operating Power Supply | -17.5 ~ -26.4 V DC (Typical -24 V DC) |
| Response Time | ≤ 1 ms |
| Working Temperature | -51 ℃ ~ +177 ℃ |
| Storage Temperature | -50 ℃ ~ +125 ℃ |
| Mounting Structure | Straight probe, sealed pressure-resistant design |
| Connection Mode | Mini coaxial ClickLoc quick connector |
| Sealing Pressure Rating | Up to 10 bar |
| Linear Error | ≤ ±1% Full Scale |
| Protection Grade | IP67 |
| Vibration Resistance | High shock resistance for machinery environment |
| Compliance Standard | API 670 Machinery Protection Standard |
| Overall Length | 50 mm probe body |
