Carbon Steel, Stainless, Alloy Fisher™ 8580 High Performance Butterfly Valve Fugitive Emission, NACE, ATEX, CUTR
The Fisher 8580 high performance Butterfly valve provides the capability for enhanced shutoff and features an eccentrically-mounted disk with either a soft or metal seal. Experience excellent throttling and on/off performance with this control valve.
Specifications
| Certifications | SIL capable, PED, CRN, Fugitive Emission, NACE, ATEX, CUTR |
| Critical Service | General Service |
| Flow Characteristics | Linear |
| Material | Carbon Steel, Stainless, Alloy |
| Operating Temperature | Standard Temperature, High Temperature |
| Power Source | Electric, Hydraulic, Pneumatic, Lever, Gear, Electro-Hydraulic |
| Pressure Class | PN, ASME |
| Process Connection Type | Flanged, Single Flanged, Double Flanged, Lugged, Wafer |
| Seat / Seal Type | Metal, Soft |
| Shutoff Class | MSS SP-61, Class IV (FCI 70-2), Class VI (FCI 70-2) |
| Standards | B16.34 |
| Stem | Live Loaded, Adjustable Packing |
| Valve Size | NPS 2, NPS 3, NPS 4, NPS 6, NPS 8, NPS 10, NPS 12 |
| Valve Size Standard | NPS, DN |
| Other Configurations |
Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product. |
Features
- The actuator/valve assembly action can be converted from push-down-to-open to push-down-to-close, or vice versa, without additional parts.
- Both the metal and soft seal rings have pressure-assisting sealing action that ensures tight shutoff regardless of pressure drop.
- Standard valve construction includes conductive packing to provide electrical bonding for hazardous area applications.
- The valve will operate at elevated temperatures, with the appropriate trim components.
- Additional travel indication can be achieved by using the indication line on the shaft, along with the disk position markings on the packing follower.
- Redundant shaft retention provides added protection. The packing follower, anti-blowout ring, and shaft groove interact to hold the shaft securely in the valve body.
Fisher 8580 Control Valve with FieldQ™ Actuator
* Testing Minimum: 1,000,000 Cycles
* Valve Body Size Range: NPS 2, 3, 4, 6, 8, 10, and 12 DN 50, 80, 100, 150, 200, 250, and 300
* Pressure Rating: CL150, 300 per ASME B16.34
* Explosion-proof applications with integral 4-20mA position feedback: TopWorx™ DXP valve controller
* Explosion-proof, intrinsically safe, non-incendive applications with integral 4–20 mA position feedback: FIELDVUE DVC6200 instrument
* Intrinsically safe, non-incendive applications with integral 4–20 mA position feedback: FIELDVUE DVC2000 instrument
