HF-KE23KW1-S100 Mitsubishi 200W MR-E Super AC Servomotors NEW In Stock 3000r/Min
Price:
Contact us
MOQ:
1
Delivery Time:
In Stock
Brand:
Mitsubishi
Product Description
Mitsubishi 200W MR-E Super AC Servomotors HF-KE23KW1-S100 NEW in stock
HF-KE23KW1-S100 Description
The HF-KE23KW1-S100 is a compact, high‑precision AC servo motor engineered for dynamic motion control in industrial automation. Delivering 200 W rated power, 0.64 Nm continuous torque, and 1.9 Nm peak torque, it combines a high‑resolution encoder (131,072 p/rev) with a rugged, space‑saving 60 mm² frame. Designed for smooth, accurate positioning and speed regulation, it supports high‑speed operation up to 4,500 rpm, making it ideal for compact machinery requiring exceptional accuracy and reliability.
HF-KE23KW1-S100 Key Features
- High Precision Control: 131,072‑pulse incremental encoder for ultra‑accurate position feedback.
- Compact & Lightweight: 60 mm × 60 mm frame, 0.94 kg weight for easy integration into tight spaces.
- High Torque Density: 0.64 Nm continuous / 1.9 Nm peak torque at 3,000 rpm.
- Wide Speed Range: Rated 3,000 rpm; maximum 4,500 rpm for versatile operation.
- IP55 Protection: Dust‑protected and splash‑resistant for industrial environments.
- Natural Convection Cooling: Fan‑less design reduces maintenance and noise.
- Low Cogging Design: Ensures smooth rotation at low speeds for precision applications.
- Industrial Grade Durability: Withstands vibration, temperature fluctuations, and electrical noise.
HF-KE23KW1-S100 Materials & Applications
Materials
- Housing: High‑strength aluminum alloy with corrosion‑resistant coating, lightweight yet rigid.
- Shaft: High‑grade alloy steel, precision‑ground for minimal runout and high wear resistance.
- Windings: Class F (155 °C) insulated copper wire for thermal stability and long life.
- Bearings: Precision‑grade ball bearings for smooth, low‑noise operation and extended service life.
- Encoder Housing: Flame‑retardant engineering plastic (UL94 V‑0) for electrical insulation and protection.
Typical Applications
- CNC Machine Tools: High‑speed spindles, linear axes, and precision positioning tables.
- Industrial Robotics: Small articulated arms, SCARA robots, and pick‑and‑place units.
- Packaging Machinery: Labelers, fillers, and form‑fill‑seal equipment requiring accurate speed control.
- Semiconductor Equipment: Wafer handling, precision stages, and inspection systems.
- Textile Machinery: Spinning, weaving, and yarn processing with tight tension control.
- General Automation: Conveyors, indexing tables, and automated assembly lines.
HF-KE23KW1-S100 Important Parameters
| Parameter | Specification |
|---|---|
| Part Number | HF-KE23KW1-S100 |
| Motor Type | AC Brushless Servo Motor |
| Rated Output Power | 200 W |
| Rated Torque | 0.64 Nm |
| Peak Torque | 1.9 Nm |
| Rated Speed | 3,000 rpm |
| Maximum Speed | 4,500 rpm |
| Encoder Type | Incremental |
| Encoder Resolution | 131,072 p/rev |
| Rated Voltage | 200 V AC (3‑phase) |
| Rated Current | 1.4 A |
| Frequency | 50/60 Hz |
| Protection Class | IP55 |
| Cooling Method | Natural convection |
| Operating Temperature | 0 °C to +40 °C |
| Storage Temperature | −15 °C to +70 °C |
| Frame Size | 60 mm × 60 mm |
| Length | 76.6 mm |
| Weight | 0.94 kg |
| Shaft Diameter | 14 mm |
| Insulation Class | F (155 °C) |
| Certifications | CE, RoHS |
MR-E Super Servomotors Selection
