Yaskawa Electric Ins B 400w Industrial 200V 3000RMP AC Servo Motor SGMAH-04AAF4C
Price:
negotiable
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Yasakawa
Product Description
Yaskawa Electric Ins B 400w Industrial 200V 3000RMP AC Servo Motor SGMAH-04AAF4C
Configuration:
Model SGMAH-04AAF4C
Product Type AC Servo Motor
Rated Output 400w
Rated Torque 1.27 Nm
Rated Speed 3000RPM
Power Supply Voltage 200vAC
Rated Current 2.8Amps
