Yasawa Electric Servo Controller 200-230VAC 100W 0.84Amp SJDE-01APA Mde in Japan


DESCRIPTION

• Industrial Servo Drive
• ServoPack
• Servo Controller

SEPCIFICATIONS

Input Main Voltage: 200-230V
Input CONT Voltage: 200-230V
Input Mian PH: 1
Input Mian Frequency:50/60HZ
Input Mian Current : 1.3A
Input CONT Current : 0.25A
Output Power :100W
Output Voltage: 0-230V
Output Current: 0.84A
Output Frequency:0-300Hz
Output PH :3
Temperture: 0-55℃
Place of Origin:Japan
Efficiency:IE 1
