41-268 Micron Stainless Steel Mesh , Stainless Steel Wire Mesh Cloth
41-268 Micron Stainless Steel Mesh , Stainless Steel Wire Mesh Cloth
Description of the Steel Screen Printing Mesh :
| Material | 304HPS |
| Weave | Plain weave |
| Features | Good Solvent Resistance |
| Aperture size | 41-268micron |
| Wire diameter | 0.018-0.02mm |
| Width | 1m,1.22m |
Featuers of the Steel Screen Printing Mesh :
High-Flexibility:The wire mesh will not lose elasticity at extremely tension.
High tension.Much higher tension than common polyester mesh,and this property is very stable.
Low Elongation:Very small elongation of wire mesh at igh tension.
Non-electrostatic:To avoid affects of nonelectrostatic for printing and ensure the safety of printing.
High-Corrosion Resistance:The excellent corrosion resistance of stainless steel wire exceeds polyester fiber.
Good Solvent Resistance:To avoid the affects of any solvents to wire mesh and to ensure the safety of printing.
Specification of the Steel Screen Printing Mesh :
| Specification | Mesh/inch | Wire Dia(μm) | Open area Ratio(%) | Apereture (μm) | Apereture(μm) | Calendered Thickness (μm) |
Theoretical lnk(cm^/m^) |
| 40*40*160 | 40 | 160 | 56 | 475 | 300-320 | As order | 179.1 |
| 60*60*120 | 60 | 120 | 51.3 | 303 | 230-245 | As order | 123.2 |
| 80*80*120 | 80 | 120 | 39 | 198 | 235-245 | As order | 92.9 |
| 80*80*90 | 80 | 90 | 52 | 228 | 175-180 | As order | 103 |
| 80*8*50 | 80 | 50 | 71 | 268 | 95-100 | As order | 78 |
| 100*100*100 | 100 | 100 | 36.8 | 154 | 195-205 | As order | 77.2 |
| 120*120*80 | 120 | 80 | 39 | 132 | 155-165 | As order | 65.8 |
| 150*150*60 | 150 | 60 | 41.7 | 109 | 115-124 | As order | 50 |
| 165*165*35 | 165 | 35 | 60 | 119 | 70-75 | As order | 48 |
| 165*165*45 | 165 | 45 | 50.1 | 109 | 88-93 | As order | 45.1 |
| 165*165*50 | 165 | 50 | 45.6 | 104 | 97-105 | As order | 45.6 |
| 180*180*45 | 180 | 45 | 46.4 | 96 | 88-93 | As order | 41.5 |
| 180*180*50 | 180 | 50 | 42 | 91 | 98-104 | As order | 41.7 |
| 200*200*40 | 200 | 40 | 46.9 | 87 | 82-84 | As order | 43 |
| 200*200*50 | 200 | 50 | 37 | 77 | 98-103 | As order | 42 |
Application of the Steel Screen Printing Mesh :
The stainless steel printing screen has many functions, such as making solar cells.pint board (PCB),chip electronic components,flat panel displays,liquid crystal display (LCD),plasma display panel (PDP), etc.
Please feel free to contact us if you wish to know more.
