1.65m Polyester Screen Printing Mesh
Plain Woven Polyester Screen Printing Mesh 47T - 55W White Bolthing Cloth
Description of the screen printing mesh:
Polyester screen printing mesh ,it is usually be called for short polyester mesh,or bolthing cloth.Our mesh width from 1m to 3.6m,mesh count from 15meo 420mesh. The most hot sale mesh have 18T , 24T , 32T , 36T , 39T , 43T , 47T , 48T , 53T, 59T , 64T , and so on!
| name | Plain Woven Polyester Screen Printing Mesh 47T - 55W White Bolthing Cloth |
| mesh count per cm | 120mesh |
| thread diameter | 55micron |
| color | white,yellow |
| opening size | 152micorn |
| width | 115cm,127cm,136cm,145cm,157cm,165cm,188cm,220cm and MAX width can be 3.65cm. |
Features of polyester screen printing mesh:
- High tension threshold and breaking point
- high modulus,low elongation monofilament polyester yarn
- Resist to chemicals, abrasion, heat and moisture
- Minimal tension loss during stretching process
- Improved registration due to stable fabric tension
- Good antistatic
- No surface treatment
Application of the screen printing mesh:
Polyester Screen printing mesh mainly used for Textile printing;--For example,white T-shirt,color -T-shirts.Crew Neck Sweatshirts,Pullover Hoodies.Zipper Hoodies,and so on!
Specification of polyester screen printing mesh
| COUNT (INCH) | COUNT (CM) | DIAMETER (UM) | OPEPING (UM) | THICKNESS(UM) | VOLUME (CM³/CM²) | MAX TEN SION(N/CM) |
| 18 | 7 | 350 | 1078 | 640 | 410 | 30-60 |
| 20 | 8 | 300 | 950 | 550 | 319 | 30-60 |
| 25 | 10 | 250 | 750 | 620 | 347 | 30-60 |
| 30 | 12 | 250 | 583 | 450 | 220 | 30-60 |
| 30 | 12 | 150 | 683 | 300 | 201 | 30-60 |
| 40 | 16 | 200 | 425 | 400 | 184 | 30-60 |
| 50 | 20 | 80 | 420 | 120 | 85 | 35-37 |
| 50 | 20 | 150 | 350 | 260 | 127 | 30-60 |
| 60 | 24 | 100 | 316 | 136 | 78 | 35-40 |
| 60 | 24 | 120 | 297 | 240 | 120 | 35-60 |
| 73 | 29 | 120 | 225 | 240 | 103 | 35-60 |
| 80 | 32 | 64 | 248 | 95 | 59 | 30-34 |
| 80 | 32 | 100 | 212 | 200 | 92 | 35-40 |
| 85 | 34 | 100 | 195 | 221 | 97 | 35-40 |
| 90 | 36 | 100 | 178 | 216 | 88 | 35-40 |
| 100 | 39 | 55 | 200 | 88 | 53 | 25-30 |
| 100 | 39 | 80 | 176 | 150 | 70 | 35-37 |
| 110 | 43 | 80 | 153 | 130 | 56 | 35-37 |
| 120 | 48 | 55 | 158 | 88 | 48 | 25-30 |
| 120 | 48 | 71 | 142 | 135 | 59 | 30-34 |
| 135 | 53 | 55 | 133 | 86 | 43 | 25-30 |
| 135 | 53 | 64 | 125 | 100 | 44 | 26-31 |
| 150 | 59 | 64 | 105 | 100 | 38 | 26-31 |
| 160 | 64 | 55 | 101 | 98 | 41 | 25-30 |
| 160 | 64 | 64 | 92 | 120 | 42 | 30-34 |
| 180 | 72 | 48 | 91 | 78 | 66 | 27-29 |
| 180 | 72 | 55 | 84 | 100 | 37 | 25-30 |
| 200 | 80 | 48 | 77 | 74 | 28 | 27-29 |
| 195 | 77 | 55 | 75 | 105 | 34 | 25-30 |
| 230 | 90 | 48 | 63 | 85 | 28 | 27-29 |
| 250 | 100 | 40 | 60 | 70 | 25 | 20-24 |
| 280 | 110 | 40 | 51 | 85 | 26 | 20-24 |
| 305 | 120 | 40 | 43 | 68 | 18 | 20-24 |
| 355 | 140 | 34 | 37 | 58 | 15 | 22-24 |
| 380 | 150 | 31 | 36 | 46 | 13 | 21-23 |
| 420 | 165 | 31 | 30 | 46 | 11 | 21-23 |
| 460 | 180 | 27 | 28 | 56 | 14 | 20-22 |
Tips of Best polyester screen printing mesh for work:
For Textile printing;
For Garment(T-shirt) printing;
For CD/DVD printing;
For Glass printing ;
For Ceramic printing ;
For Electronics components printing;
And so on...
Packing of polyester screen printing mesh:
- mesh rolls in a pp bag
- 2-12rolls per cartons
- waterproof bags outside
- package belt strengthen
