304 Material 18 / 8 Stainless Steel Filter Plain Weave Wire Mesh For Medical Industry

Name: 304 Material 18 / 8 Stainless Steel Filter Plain Weave Wire Mesh For Medical Industry
Brand: Hebei Reking Wire Mesh CO.,Ltd

Price Negotiable

Price: Negotiate

MOQ: 1 squaremeter

Delivery Time: 5-8 workday

Brand: R&K

Product Description

304 Material 18 / 8 Stainless Steel Filter Plain Weave Wire Mesh For Medical Industry

304 stainless steel is a common material in stainless steel, with a density of 7.93 g/cm, and is also called 18/8 stainless steel in the industry. It can withstand high temperature of 800℃, has good processing performance and high toughness. It is widely used in industry and furniture decoration industry as well as food and medical industry.

Material	SS 304
Tensile strength	b (MPa)≥515-1035
The yield strength	0.2 (MPa)≥205
Elongation	5 (%)≥40
Hardness	201 HBW or less
Density (20℃, g/cm)	7.93
Melting point (℃)	1398~1454
Resistivity (20 ℃, 10-6 Ω m2 / m)	0.73

(Plain weave ) (Twill weave )

Stainless steel: stainless steel, with wear resistance, heat resistance, acid resistance and corrosion resistance. Many different grades of stainless steel are used for wire cloth. T304 is the most common, but others are used for specific applications to take advantage of the unique properties of each grade. Wire mesh made of stainless steel is widely used in the mining, chemical, food and pharmaceutical industries.
Our stainless steel wire mesh products are generally made of stainless steels 302, 304, 304L, 316, 316L, 321 and 430. We produce wire mesh in various forms. Weaving is determined according to the specific requirements of the customer, such as material, wire diameter, mesh size, width and length.

Plain weave: Each weft thread passes through one and one warp thread, each warp thread passes through one and one weft thread, and each weft thread has warp threads of the same diameter.
Features: square hole, high circulation, relatively high opening area, so the pressure drop during filtration is small, suitable for various filtration below 63μm.

Package of the stainless steel wire mesh

A roll wrapped in kraft paper and then placed in a carton or tray;
Sheets are in a wooden box or tray.

Parameter of stainless steel mesh

mesh	Wire Diameter		Aperture		Open Area	Weight
	Wire Diameter		Aperture		Open Area	Weight
	Inch	MM	Inch	MM	(%)	(kg /Square meter)
1x1	0.08	2.03	0.92	23.37	92	2
2X2	0.063	1.6	0.437	11.1	87.4	2.5
3X3	0.054	1.37	0.279	7.09	83.8	2.7
4X4	0.047	1.19	0.203	5.16	81.2	2.7
5X5	0.041	1.04	0.159	4.04	79.5	2.6
8X8	0.02	0.5	0.105	2.675	71	1
9X9	0.02	0.5	0.091	2.32	67.7	1.1
10X10	0.025	0.64	0.075	1.91	74.9	2
12X12	0.02	0.508	0.063	1.6	75.9	1.5
12X12	0.022	0.55	0.062	1.567	54.8	1.815
14X14	0.02	0.508	0.051	1.3	71.9	1.8
14X14	0.0177	0.45	0.054	1.36	75.14	1.417
16X16	0.016	0.4	0.047	1.188	55	1.28
16X16	0.018	0.457	0.0445	1.13	71.2	1.6
18X18	0.017	0.432	0.0386	0.98	69.4	1.6
20X20	0.02	0.24	0.03	0.76	76	0.56
20X20	0.016	0.33	0.034	0.86	72.2	1.1
20X20	0.014	0.35	0.036	0.92	52.5	1.225
20X20	0.016	0.4	0.034	0.87	46.9	1.6
20X20	0.0177	0.45	0.0322	0.82	41.7	2.025
22X22	0.012	0.3	0.034	0.854	54.76	0.99
24X24	0.014	0.35	0.028	0.708	44.77	1.47
30X30	0.014	0.35	0.0195	0.5	34.6	1.84
30X30	0.012	0.305	0.0213	0.54	63.9	1.4
30X30	0.0094	0.24	0.0243	0.62	72.1	0.84
35X35	0.0079	0.2	0.021	0.526	52.5	0.7
35X35	0.0098	0.25	0.0187	0.475	42.92	1.09
40X40	0.0079	0.2	0.017	0.435	46.9	0.8
40X40	0.01	0.254	0.015	0.38	59.9	1.3
40X40	0.014	0.35	0.011	0.285	20.14	2.45
50X50	0.0055	0.14	0.0145	0.368	72.4	0.48
50X50	0.0079	0.2	0.012	0.308	36.76	1
60X60	0.0047	0.12	0.012	0.303	71.6	0.42
60X60	0.0059	0.15	0.0107	0.273	64.5	0.65
60X60	0.007	0.18	0.0096	0.243	33	0.972
80X80	0.047	0.12	0.0078	0.1975	38.7	0.576
80X80	0.0055	0.14	0.0069	0.117	45.5	0.76
100X100	0.0039	0.1	0.006	0.154	36.76	0.5
100X100	0.0045	0.114	0.0055	0.14	55.1	0.59
100X100	0.004	0.102	0.006	0.152	59.8	0.49
120X120	0.0028	0.07	0.0057	0.147	67.7	0.29
120X120	0.003	0.08	0.0052	0.132	38.7	0.384
150X150	0.0024	0.06	0.0043	0.11	64.7	0.26
150X150	0.0028	0.07	0.0039	0.1	58.8	0.38
165X165	0.0019	0.05	0.0041	0.104	67.5	0.2
180X180	0.0019	0.05	0.0035	0.091	64.5	0.22
180X180	0.0024	0.06	0.0031	0.081	57.4	0.32
200X200	0.0019	0.05	0.003	0.077	60.6	0.24
200X200	0.0024	0.06	0.0026	0.067	52.7	0.35
250X250	0.0016	0.04	0.0024	0.0616	60.6	0.2
270X270	0.0016	0.04	0.0021	0.054	57.4	0.21
300X300	0.0016	0.04	0.0018	0.045	53.5	0.23
325X325	0.0014	0.035	0.0017	0.0432	55.3	0.2
400X400	0.0012	0.03	0.0013	0.0335	52.7	0.18
500X500	0.0009	0.025	0.001	0.0258	50.7	0.15
500X500	0.0012	0.03	0.0008	0.0208	16.76	0.225
635X635	0.0007	0.018	0.0008	0.022	55	0.1
