18 20 Mesh 100 MM Stainless Steel Woven Wire Mesh Panels Filter Screen Oil Filter
18 20 Mesh 100 MM Stainless Steel Woven Wire Mesh Panels Filter Screen Oil Filter
Wire mesh can be used for various screening, construction, protection and filtration applications. In addition, the wire cloth also helps: EMI/FEI shielding, belt manufacturing, light diffusion, heat and flame diffusion, plastic extrusion, banknotes and banknote watermarks, and optical lens manufacturing.
Industrial wire mesh and wire mesh applications include: construction screens, HVAC units, discharge of pulp and other mixtures, and sorting and screening machines.
There are many types of stainless steel nets, and some nets are used for decoration. Applications include residential fireplace guards, residential and commercial kitchen cabinets. By comparing the material with the opening size of the mesh itself, a hard cloth can also be used to determine the particle size of the material.
Some screens can also serve some industries, including electronics, mining, industrial manufacturing, battery manufacturing, automobile manufacturing, food and beverage, pulp and paper, petrochemical processing, HVAC, pharmaceuticals, flooring, mining, household appliances and screens print.
Package
Specification
| mesh | Wire Diameter | Aperture | Open Area | Weight | ||
| Inch | MM | Inch | MM | (%) | (kg /Square meter) | |
| 1x1 | 0.08 | 2.03 | 0.92 | 23.37 | 92 | 2 |
| 2X2 | 0.063 | 1.6 | 0.437 | 11.1 | 87.4 | 2.5 |
| 3X3 | 0.054 | 1.37 | 0.279 | 7.09 | 83.8 | 2.7 |
| 4X4 | 0.047 | 1.19 | 0.203 | 5.16 | 81.2 | 2.7 |
| 5X5 | 0.041 | 1.04 | 0.159 | 4.04 | 79.5 | 2.6 |
| 8X8 | 0.02 | 0.5 | 0.105 | 2.675 | 71 | 1 |
| 9X9 | 0.02 | 0.5 | 0.091 | 2.32 | 67.7 | 1.1 |
| 10X10 | 0.025 | 0.64 | 0.075 | 1.91 | 74.9 | 2 |
| 12X12 | 0.02 | 0.508 | 0.063 | 1.6 | 75.9 | 1.5 |
| 12X12 | 0.022 | 0.55 | 0.062 | 1.567 | 54.8 | 1.815 |
| 14X14 | 0.02 | 0.508 | 0.051 | 1.3 | 71.9 | 1.8 |
| 14X14 | 0.0177 | 0.45 | 0.054 | 1.36 | 75.14 | 1.417 |
| 16X16 | 0.016 | 0.4 | 0.047 | 1.188 | 55 | 1.28 |
| 16X16 | 0.018 | 0.457 | 0.0445 | 1.13 | 71.2 | 1.6 |
| 18X18 | 0.017 | 0.432 | 0.0386 | 0.98 | 69.4 | 1.6 |
| 20X20 | 0.02 | 0.24 | 0.03 | 0.76 | 76 | 0.56 |
| 20X20 | 0.016 | 0.33 | 0.034 | 0.86 | 72.2 | 1.1 |
| 20X20 | 0.014 | 0.35 | 0.036 | 0.92 | 52.5 | 1.225 |
| 20X20 | 0.016 | 0.4 | 0.034 | 0.87 | 46.9 | 1.6 |
| 20X20 | 0.0177 | 0.45 | 0.0322 | 0.82 | 41.7 | 2.025 |
| 22X22 | 0.012 | 0.3 | 0.034 | 0.854 | 54.76 | 0.99 |
| 24X24 | 0.014 | 0.35 | 0.028 | 0.708 | 44.77 | 1.47 |
| 30X30 | 0.014 | 0.35 | 0.0195 | 0.5 | 34.6 | 1.84 |
| 30X30 | 0.012 | 0.305 | 0.0213 | 0.54 | 63.9 | 1.4 |
| 30X30 | 0.0094 | 0.24 | 0.0243 | 0.62 | 72.1 | 0.84 |
| 35X35 | 0.0079 | 0.2 | 0.021 | 0.526 | 52.5 | 0.7 |
| 35X35 | 0.0098 | 0.25 | 0.0187 | 0.475 | 42.92 | 1.09 |
| 40X40 | 0.0079 | 0.2 | 0.017 | 0.435 | 46.9 | 0.8 |
| 40X40 | 0.01 | 0.254 | 0.015 | 0.38 | 59.9 | 1.3 |
| 40X40 | 0.014 | 0.35 | 0.011 | 0.285 | 20.14 | 2.45 |
| 50X50 | 0.0055 | 0.14 | 0.0145 | 0.368 | 72.4 | 0.48 |
| 50X50 | 0.0079 | 0.2 | 0.012 | 0.308 | 36.76 | 1 |
| 60X60 | 0.0047 | 0.12 | 0.012 | 0.303 | 71.6 | 0.42 |
| 60X60 | 0.0059 | 0.15 | 0.0107 | 0.273 | 64.5 | 0.65 |
| 60X60 | 0.007 | 0.18 | 0.0096 | 0.243 | 33 | 0.972 |
| 80X80 | 0.047 | 0.12 | 0.0078 | 0.1975 | 38.7 | 0.576 |
| 80X80 | 0.0055 | 0.14 | 0.0069 | 0.117 | 45.5 | 0.76 |
| 100X100 | 0.0039 | 0.1 | 0.006 | 0.154 | 36.76 | 0.5 |
