2.2 Meters Width Monofilament Fine Woven Wire Mesh Plain Weave
Monofilament Stainless Steel Screen Printing Mesh 2.2 Meters Width Plain Weave
Product Introduction
Screen printing refers to the use of screen as a plate base, and through the photosensitive plate making method, made with graphic screen printing plate. Screen Printing is generally divided into stainless steel printing mesh and polyester printing mesh
Procuct Feaures
Suitable for gas, liquid filtration and other media separation
Not easy to rust, heat resistance, acid and alkali resistance, corrosion resistance
The number of items is complete, and the trial range of different items is different
Accurate in mesh size,high flow rate.
High efficient screeing,good stability,high opening rate,Low pressure loss.
Product Application
1. Accurate mesh, good production reproducibility;
2. Good acid, alkali and corrosion resistance;
3. High strength, tensile force, toughness and wear resistance, long service life;
4. Unified structure, no curl, easy to use, uniform thickness, anti-static;
5. High temperature oxidation resistance, 304 stainless steel screen nominal temperature of 800 degrees Celsius,
6 normal temperature processing, that is, easy plastic processing, so that the use of stainless steel screen diversification;
7. High finish, no surface treatment, easy maintenance!
Product Specification
| Specification | Mesh/inch | Wire Dia.(μm) | Open area Ratio(%) | Aperture(μm) | Thickness(μm) | Calendered Thickness(μm) | Theoretical Ink(cm³/m²) |
| 40*40*160 | 40 | 160 | 56.0 | 475 | 300-320 | As order | 179.1 |
| 60*60*120 | 60 | 120 | 51.3 | 303 | 230-245 | As order | 123.2 |
| 80*80*120 | 80 | 120 | 39.0 | 198 | 235-245 | As order | 92.9 |
| 80*80*90 | 80 | 90 | 52.0 | 228 | 175-180 | As order | 103.0 |
| 80*80*50 | 80 | 50 | 71.0 | 268 | 95-100 | As order | 78.0 |
| 100*100*100 | 100 | 100 | 36.8 | 154 | 195-205 | As order | 77.2 |
| 120*120*80 | 120 | 80 | 39.0 | 132 | 155-165 | As order | 65.8 |
| 150*150*60 | 150 | 60 | 41.7 | 109 | 115-124 | As order | 50.0 |
| 165*165*35 | 165 | 35 | 60.0 | 119 | 70-75 | As order | 48.0 |
| 165*165*45 | 165 | 45 | 50.1 | 109 | 88-93 | As order | 45.1 |
| 165*165*50 | 165 | 50 | 45.6 | 104 | 97-105 | As order | 45.6 |
| 180*180*45 | 180 | 45 | 46.4 | 96 | 88-93 | As order | 41.5 |
| 180*180*50 | 180 | 50 | 42.0 | 91 | 98-104 | As order | 41.7 |
| 200*200*40 | 200 | 40 | 46.9 | 87 | 82-84 | As order | 43.0 |
| 200*200*50 | 200 | 50 | 37.0 | 77 | 98-103 | As order | 42.0 |
| 230*230*35 | 230 | 35 | 46.7 | 75 | 72-76 | 50-67 | 37.0 |
| 250*250*40 | 250 | 40 | 36.8 | 62 | 86-86 | 50-80 | 34.0 |
| 250*250*30 | 250 | 30 | 49.7 | 72 | 64-68 | 40-58 | 30.0 |
| 250*250*35 | 250 | 35 | 43.0 | 67 | 76-78 | 57-70 | 32.0 |
| 270*270*35 | 270 | 35 | 39.4 | 59 | 76-80 | 58-70 | 30.0 |
| 300*300*30 | 300 | 30 | 41.7 | 55 | 66-68 | 40-59 | 28.0 |
| 325*325*30 | 325 | 30 | 38.0 | 48 | 66-68 | 45-60 | 24.0 |
| 325*325*28 | 325 | 28 | 41.2 | 50 | 63-64 | 40-56 | 26.4 |
| 325*325*23 | 325 | 23 | 49.8 | 55 | 49-53 | 37-41 | 25.4 |
| 350*350*25 | 350 | 25 | 43.0 | 48 | 52-54 | 41-50 | 18.7 |
| 400*400*23 | 400 | 23 | 40.7 | 41 | 50-54 | 35-48 | 19.0 |
| 400*400*18 | 400 | 18 | 51.3 | 46 | 36-40 | 28-30 | 20.0 |
| 500*500*18 | 500 | 18 | 41.7 | 33 | 36-40 | 23-29 | 15.3 |
