Long Lengthes Oil Containment Boom Favorable Flotation Performance OEM Received
High Quality Pvc Solid Flotation Performance Oil Containment Boom
Oil boom is an important equipment that was adapted for use on the sea or other water to control oil spill. It is specially adapted for permanent installation on open seas, bays, harbors and docks. It can be used in oil spill response.
The solid float PVC boom is an economical,universal boom for intercepting oil spills and other floats on waters.It is suitable for the permanent,stationary deployment on waters.Thanks to its fast deployment and easy operation,it is widely used on rivers,harbors,lakes,offshore oil platforms and other waters.
Features of FL oil containment boom
* Made of the high strength fabric coated with orange PVC on its two sides,having excellent
resistance to oil and aging.
* The solid float have a large capacity of buoyancy and excellent wave riding and steadiness.
* The boom body is provided with a pulling rope,a strength ribbon and tensile ballast chains
serving as elements for withstand forces and has high tensile strength.
Technical data of oil containment boom
| Model |
WGV 600 |
WGV 700 |
WGV 750 |
WGV 800 |
WGV 900 |
WGV 1000 |
WGV 1100 |
WGV 1500 |
|
|
Overall height (mm) |
600 | 700 | 750 | 800 | 900 | 1000 | 1100 | 1500 | |
| Freeboard(mm) | 150 | 210 | 260 | 280 | 320 | 340 | 370 | 520 | |
| Draft(mm) | 380 | 390 | 400 | 420 | 490 | 540 | 560 | 760 | |
|
Length per section(m) |
20 | ||||||||
|
Max working tensile strength (KN) |
20 | 25 | 30 | 45 | 55 | 75 | 85 | 130 | |
|
Max wave Height to withstand(m) |
0.5 | 0.5 | 1 | 1.5 | 1.8 | 2 | 2 | 3 | |
|
Max wind speed to withstand(m/s) |
8 | 10 | 10 | 15 | 15 | 18 | 20 | 20 | |
|
Max current speed to withstand(KN) |
1 | 1 | 1.5 | 1.5 | 2 | 2.5 | 2.5 | 3 | |
FAQ
Q1: What’s the material of your products?
A: Our raw material is PVC
Q2: Can you do OEM?
A: Yes,we can do.As long as receive your request,we could produce accordingly.
Q3: What’s your delivery time and payment terms?
A: Delivery time is according to customers’ size and order qty.The payment terms you could choose are T/T,L/C at sight,Western Union and so on.
Q4: What about your warranty time?
A: Our warranty period is 24 months.During this time,any problems about products from our factory,we solemn promise to change and repair them for free;if problems from customers’ improper operating,we could provide free guidance and repair materials
