Boat Inflation Marine Rubber Fender Black Color 10 Years Design Using Life

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 5-10 work days
Brand: Florescence RUBBER
Product Description

Tires And Chains Protected Of Boat Inflation Yokohama Marine Rubber Fender

In order to produce the qualified and famous China Brand of pneumatic fenders , Florescence
RUBBER invested the advanced production and test equipments, and invited the foreign experienced engineers of pneumatic fenders, which ensure all Florescence
 pneumatic fenders are manufactured comply with ISO17357:2002. Therefore, Florescence
-RUBBER is the unique manufacturer of ISO17357 qualified Pneumatic Fenders in China.

In order to protect your maritime values,Florescence
-RUBBER strongly recommends the use of ISO certified Pneumatic Fenders while performing the high quality needed for safe berthing during ship to ship operations involving bunkering or discharging of oil or gas, and ship to port operation

Notes about  rubber fender

* Frequently check whether the fender body si damaged and whether the pressure is normal,and the valve core must be replaced every six moths

* The steel wire should wrap the rubber pipe,when trying steel wire to pneumatic rubber fender in case the fender is stabbed

* The surface or subject next to the pneumatic rubber fender can’t be hard and sharp-pointed in case the pneumatic rubber fender is stabbed

* The accessories and jip’s nuts can’t be loose when testing the internal pressure

* The rope net should be reliable,the steel wire used for hanging metal parts and the hook link can’t be tied in disorder.

Storage of FL rubber fender

* When not using for a long time,wash the surface of the fender,dry up and fill in sufficient right amount of compressed air to lay them in a cool.dry and well-ventilated place.

* The storage place of pneumatic rubber fender should be far away from hear source

* Try to keep fender away from acid,alkali,grease and organic solvents

* When not applying the fenders,the pneumatic rubber fender can’t be piled up and heavy items can’t be piled on the fender

Technical performance of marine rubber fender

Specification
DXL(m)

0.05Mpa(Initial pressure 0.05Mpa)(Initial pressure 0.08Mpa)
Weight(kg)Reaction force(KN)

GEA
(KJ)

Weight
(kg)

Reaction force(KN)

GEA
(KJ)

0.5X1.025674625858
0.6X1.032748329811
0.7X1.550137175018024
1.0X1.580182328023945
1.0X2.01002574512533863
1.2X2.01202976316539088
1.35X2.5165427102226561142
1.5X3.0315579153370761214
1.7X3.0405639191436840287
2.0X3.55908753086321150430
2.5X4.01050138166311101815925
2.5X5.513332019943141026531317
3.0X5.0188020001050215527091571
3.0X6.0216024881312247032921888
3.3X4.5202018841175230024761640
3.3X6.0230027831675260036522338
3.3X6.5270030151814308039612532
3.3X10.6440352573067502069074281
4.5X9.0655457474752747075516633
4.5X128739798464739960104909037
Note:The weight is the fender body weight(without tires and chain),with weight error of ±10% and counterforce error of ±10%
