Ship Floating Marine Salvage Lift Bags , Inflatable Buoyancy Bags Anti Wear Characteristic
Rubber Inflatable Salvage Buoy / Ship Floating Rubber Airbag / Marine Salvage Airbags
FL salvage / refloatation marine airbags are the most commonly used tool for recovering submerged objects and supply enough buoyancy for objects. Floating FL marine airbags are very small in size while deflated. Thus, they can be easily transported and deployed when space is an issue and under water conditions. We can provide the exact floating ton capability based on clients requirements. The FL salvage refloatation airbags have flexible applications and can be broadly implemented in shipwreck salvaging, floating bridge and dock construction, rescue and remove of wrecked ships. It is also being use as temporary marine transportation device
Advantages of Florescence inflatable rubber airbag
1. Big carrying capacity
2. High capacity against compression and twisting
3. New design of anti-bursting construction at the end
4. Optimized structural layout
5. Durable aging resistance and anti-wear characteristic
6. Higher flexibility and damping capacity
Standard specifications of Florescence inflatable rubber airbag
1> Diameter (D): From 0.3m to 2.2 m.
2> Effective Length (EL): From 6m to24m.
3> Total Length (TL): From 7m to28m.
4> Other specification of ship launching airbags also available upon customer’s request
surface area and volume of marine salvage airbags
| L | D=1.0m | D=1.2m | D=1.5m | D=1.8m | D=2.0m | |||||
| (㎡) | (m3) | (㎡) | (m3) | (㎡) | (m3) | (㎡) | (m3) | (㎡) | (m3) | |
| 5m | 18.85 | 4.38 | 23.37 | 6.44 | 30.63 | 10.36 | 38.45 | 15.37 | 43.98 | 19.33 |
| 6m | 21.99 | 5.17 | 27.14 | 7.57 | 35.34 | 12.13 | 44.11 | 17.91 | 50.27 | 22.47 |
| 7m | 25.13 | 5.95 | 30.91 | 8.70 | 40.06 | 13.90 | 49.76 | 20.45 | 56.52 | 25.62 |
| 8m | 28.27 | 6.74 | 34.68 | 9.83 | 44.77 | 15.67 | 55.42 | 23.00 | 62.83 | 28.76 |
| 9m | 31.42 | 7.52 | 38.45 | 10.96 | 49.48 | 17.43 | 61.07 | 25.54 | 69.12 | 31.90 |
| 10m | 34.56 | 8.31 | 42.22 | 12.09 | 54.19 | 19.20 | 66.73 | 28.09 | 75.40 | 35.04 |
| 11m | 37.70 | 9.09 | 45.99 | 13.22 | 58.90 | 20.97 | 72.38 | 30.63 | 81.68 | 38.18 |
| 12m | 40.84 | 9.88 | 49.76 | 14.35 | 63.62 | 22.73 | 78.04 | 33.18 | 87.96 | 41.32 |
| 13m | 43.98 | 10.66 | 53.53 | 15.49 | 68.33 | 24.50 | 83.69 | 35.72 | 94.25 | 44.46 |
| 14m | 47.12 | 11.45 | 57.30 | 16.62 | 73.04 | 26.27 | 89.35 | 38.27 | 100.53 | 47.61 |
| 15m | 50.27 | 12.23 | 61.07 | 17.75 | 77.75 | 28.04 | 95.00 | 40.81 | 106.81 | 50.75 |
| 16m | 53.41 | 13.02 | 64.84 | 18.88 | 82.47 | 29.80 | 100.66 | 43.36 | 113.10 | 53.89 |
| 17m | 56.55 | 13.80 | 68.61 | 20.01 | 87.18 | 31.57 | 106.31 | 45.90 | 119.38 | 57.03 |
| 18m | 59.69 | 14.59 | 72.38 | 21.14 | 91.89 | 33.34 | 111.97 | 48.45 | 125.66 | 60.17 |
FAQ
Q1: What’s your delivery time and payment terms?
A: Delivery time is according to customers’ size and order qty.The payment terms you could choose are T/T,L/C at sight,Western Union and so on.
Q2: How can I get samples from you?
A: We are honored to provide you samples for check quality.Customers just confirm freight collect and then we could send out the sample by FedEx,DHL,UPS,TNT and so on.
Q3: What’s certificates can your company provide?
A: We can provide CCS,ABS,DNV,LR,BV certificates.
Q4: What about your warranty time?
A: Our warranty period is 24 months.During this time,any problems about products from our factory,we solemn promise to change and repair them for free;if problems from customers’ improper operating,we could provide free guidance and repair materials
