Florescence Brand Stern W Rubber Fender Marine Equipment
Price:
200
MOQ:
1
Delivery Time:
within 10 days
Brand:
Florescence
Product Description
High Quality Florescence Brand Stern W Rubber Fender, Marine Equipment
Stern W Rubber Fender
Tug Fendering is supplied in a variety of styles and profiles to suit the large range of operational tugs, pusher barges and work boats. The most used profiles being.
Stern W Rubber Fender Arrangement
• Cylindrical profile with chain recesses for bow and stern protection. • “W” style fender for applications that require a large curved hull area to be protected. • Block fender for hard wearing applications where replacement may be more frequent. • Square and “D” shaped profiles for side protection of vessels
Cylindrical Fender
Cylindrical Bow & Stern Fender
Cylindrical Bow & Stern Fenders are commonly used on ocean going tugs and where ignificant movement occurs between the tug and ship. This fender is commonly used in conjunction with Block or M-Fender to accommodate vessels with large bow flare such as container vessels.
Special features of the Cylindrical Bow and Stern Fender include tapered ends, protective end plates and groove to
accommodate circumferential securing chains or straps. Single fender can be manufactured up to 800mm diameter
and 13 metres in length (subject to transport limitations.) Longer fender sections can be made by joining shorter sections
with joining plugs.
Our cylindrical fenders are perfect for use in applications which need protection from large objects and impact.
We specifically design these fenders to offer the maximum compression rates possible without the fender warping or deteriorating.
Curve Radius
Cylindrical Fenders are produce in straight lengths but can be pulled around radiused hull provided that the inside radius is at least four times the outside diameter of the fender.
W fender
W fender
W-Fenders are specially designed as vertical fenders for the bow and stern of tugs. It’s unique profile is able to accomodate the tight radius and closely follow the ship’s contours. The wider external face present a continue and uniform surfaces thus providing an unbroken protective surfaces at the bow and stern of tugboats.
The special shape of the W-Fenders offer savings in weight and installation advantages - reduce both the initial purchase and installation cost.
Dimensional Tolerance Cross Section : > 100mm : ± 4%, or < 100mm : ISO3302-1, Class E3 Length : ± 20mm
Extruded Fender
Extruded Fender
Extruded Fender is able to be delivered with fixing points, i.e. holes drilled into the fender, sloping ends, fixing plates, bolts and accessories.
Extruded fenders are normally used as side fendering on tugs, supply
vessels and pilot boats.
Typical Mounting Details For Ships
