Safe Food Belt Conveyor Metal Detectors , Bakery Metal Detector HACCP / CE Certified
Safe Food and HACCP , CE Certified Conveyor Belt Metal Detector
Detect all Types of Metal Including Stainless Steel
Suitable for metal contaminants detection in various industries like: Aquatic Products, Meat & Poultry, Salted Products, Pastry, Nuts, Vegetables, Chemical Raw Materials, Pharmacy, Cosmetics, Toys.
Detecting all metal contaminants in packaged and non-packaged food, including ferrous metal (Fe), non-ferrous metals (Copper, Aluminum etc.) and Stainless Steel.
Application-Specific Solutions
With a wide range of aperture size ranges and feature sets, Safeline tunnel metal detectors for conveyor systems offer an ideal solution to detect all types of metal for inline food and non-food processing applications.
Metal Detectors VDF Series
- Stable and high sensitivity
- Auto-setting function
- User friendly function
- Dust and water proof, easy to be cleaned
1. New function
2. Hardware structure optimization
3. User friendly function
4. IP66 Dust and water proof
Specifications
| Model | VDF | VDF | |||
| Detection Width | 400mm | 500mm | 400mm | 500mm | |
| Detection Height |
80mm,120mm 150mm,180mm |
200mm 250mm |
80mm,120mm 150mm,180mm |
200mm 250mm |
|
| Sensitivity | Fe |
?0.5mm,?0.6mm ?0.7mm,?0.8mm |
?1.0mm ?1.2mm |
?0.5mm,?0.6mm ?0.7mm,?0.8mm |
?1.0mm ?1.2mm |
| SUS304 |
?1.0mm?1.2mm ?1.5mm?2.0mm |
?2.0mm ?2.5mm |
?0.8mm,?1.0mm ?1.2mm,?1.5mm |
?1.5mm ?2.0mm |
|
| Belt Width | 360mm | 460mm | 360mm | 460mm | |
| Loading Capacity | 5kg~10kg | 20kg~100kg | 5kg~10kg | 20kg~100kg | |
| Display Mode | D Liquid Crystal (FDM touch screen is optional) | ||||
| Operation Mode | Button Input (touch input is optional) | ||||
| Product Storage Quantity | 52 kinds | ||||
| Packing Form | Standard plastic or cardboard, metal film (aluminum) and bulk | ||||
| Conveyor Belt | Food Grade PVC (PU and Chain Conveyor are optional) | ||||
| Belt Speed | Fixed 25m/min (Variable speed is optional) | ||||
| Alarm | Alarm and belt stops (Alarm lamp and rejecter are optional) | ||||
| Power Supply | AC220V (Optional) | ||||
| Main Material | SUS304 | ||||
Note
- 1. The technical parameter above namely is the result of sensitivity by detecting only the test sample on the belt. The sensitivity would be affected according to the products being detected, working condition and also the different positions the metal mixed with.
- 2. Requirements for different sizes by customers can be fulfilled.
1. Are you manufacturer or trader?
We are manufacturer, we have own factory in Dong Guan, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation, believe our team is best team in china.
2. Do you sell the accessories for Products ?
Yes. We have Match the parts for our testing equipment. If our machines damages by fire, water flood, earthquakes, unsteady of power and other natural disasters, we are willing supply match parts with lowest price for you.
3.How about the packing for product? Is it easy damaged during transportation?
For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case.
Every prepackage have a plastic bags cover .
4.How about your after-sales policy?
Customer first is our always principle . All of our products normal warranty is 12months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .
5.Do you accept customer Logo and customized ?
we accept kinds of customized and logo of all of our products for customers
