Crush Resistance Optical Fiber Patch Cable 1 Or 2 Cores GJYXCH Black Color
Price:
negotiation
MOQ:
500M+500M or 1KM
Delivery Time:
Negotiable
Brand:
HICORPWELL
Product Description
FTTH G657A1 fiber optical cable 1km price 1 cores 2 cores GJYXCH
Characteristic
Special low-bend-sensitivity fiber provides high bandwidth and excellent communication
transmission property;
Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber;
Single steel wire or massagers as the additional strength member ensures good performance of tensile strength.
Simple structure, light weight and high practicability;
Novel flute design, easily strip and splice, simplify the installation and maintenance
Geometrical Characteristics
| Fiber Core | 1 | 2 | 4 | 6 |
| Cable Dimension(mm) | 2.0x5.0 | 2.0x5.0 | 2.0x5.5 | 2.0x6.0 |
| Cable Weight (kg/km) | 20 | 20 | 21 | 21 |
Mechanical Characteristics
| Tensile strength(N) | Long Term | 60 |
| Short Term | 120 | |
| Bending Radius(CM) | Dynamic | 35 |
| Static | 15 |
Fiber
| Fiber Type(core/cladding dimension) | G.657A,G.652D |
Transmission Characteristics
| SMF | |
| 1310/1550(nm) | |
| Attenuation(db/km) | ≤0.4/0.30 |
| Minimum Bandwidth(MHz·km) | ----------------------- |
Environmental Characteristics
| Storage Operating Temperature | -20℃~+60℃ |
SM Optic Fiber Characteristics
| Type | G.652D | G.657A | 50/125μm | 62.5/125μm | |
| Attenuation(+20℃) | @850nm | ≤3.0dB/km | ≤3.5dB/km | ||
| @1300nm | ≤1.5dB/km | ≤1.5dB/km | |||
| @1310nm | ≤0.40dB/km | ≤0.35dB/km | |||
| @1500nm | ≤0.30dB/km | ≤0.25dB/km | |||
| Bandwidth(Class A) | @850nm | ≥500Mhz.km | ≥200Mhz.km | ||
| @1300nm | ≥1000Mhz.km | ≥600Mhz.km | |||
| Numerical Aperture | 0.200±0.015NA | 0.275±0.015NA | |||
| Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm | |||
