SFP-GE-T-RJ45 SFP+ CAT6 CAT6A 10G Ethernet Fiber Optic Transceiver

Support 1000base-T

Hot-pluggable SFP footprint

Compact RJ-45 connector assembly

RoHS compliant and lead-free

Single +3.3V power supply

10 Gigabit Ethernet over Cat 6a cable

Ambient Operating temperature: 0°C to +65°C

Applications

Gigabit Ethernet

Fiber Channel

Switch to Switch interface

Switched backplane applications

Router/Server interface

Other Optical Links

Product Descriptions

1000base-T Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA) . They are compatible with the 1000base-T standards as specified in IEEE Std 802.3 . 1000base-T uses the SFP's RX_LOS pin for link indication. If pull up SFP's TX_DISABLE pin, PHY IC be reset.
