Capcitive Outdoor Digital Signage , Touch Screen Kiosk Stand For Road Advertising Sign
Capcitive Touch Standing Outdoor Waterproof Information Kiosk Road Advertising Sign Interactive Way Finder
Main features
1. IP65 design for outdoor application.
2. High brightness up to 2000cd/m2, readable under sunlight.
3. Build in Airconditioner cooling system, adapted to -40°C--+60°C environment temperature.
4. Fron tempered glass and anti-glare glass
5. Intelligent light system, brightness of screen auto adjusts according to environment light, saving energy.
6. Anti-dust, anti-vandal, anti-theft.
7. Customized design for you without additional cost.
8. Screen sizes available 19-82inch
9. Wall mount, roof hanging and free standing(fixed on ground) all available.
10. Security electric circuit design
11. Build in power timer
|
Items |
Touch Screen Specifications |
|
Touch type |
Infrared sensor |
|
Typical feature |
Dustproof, vandal proof, anti-sunlight |
|
Touch points |
Multi 2points to 32points |
|
Accuracy |
±2mm |
|
Light transmittance |
Over 92% |
|
Surface hardness |
7H |
|
Output resolution |
4096X4096 |
|
Respond time |
Less than 8ms |
|
Life span |
Over 60,000,000 single point touch |
|
Items |
Touch Foil Film Specifications |
|
Touch type |
Projected capacitive touch |
|
Typical feature |
Touch through tempered glass |
|
Touch points |
Multi 2points to 40points |
|
Accuracy |
≤1mm |
|
Light transmittance |
Over 95% |
|
Scanning speed |
16ms |
|
Output solution |
4096X4096 |
|
Safe distance |
At least 3mm (between TFT LCD and touch foil) |
|
Life span |
7-9 years |
Specification:
|
screen specs |
Screen size: |
55" |
|
Display ratio: |
16:9 |
|
|
Resolution(Pixel): |
1920*1080 |
|
|
View angle : |
89/89/89/89 |
|
|
Luminance: |
1500 cd/m2,2000cd/m2 , 2500cd/m2 , 2500cd/m2 , 3000cd/m2 3500cd/m2 ,4000cd/m2 ,5000cd/m2 |
|
|
Contrast ratio: |
5000:1 |
|
|
Response time : |
8ms |
|
|
Display area: |
1209.6*680.4 mm |
|
|
Touch screen optional |
Capacitive touch screen / Infrared touch screen / Nano touch screen |
|
|
Parameter |
Operating temperature: |
-40°C--+60°C |
|
Protection Rating: |
IP65 |
|
|
Storage Temperature: |
0-50 degrees |
|
|
Humidity :5%-100% |
||
|
Temperature control system(optional) |
Air conditioner |
Voltage Rated:AC110V/60Hz OR other Current Rated:AC 6.5A Power Rated:AC 500W Cooling Capacity:1500W(L35 L35) Heating Capacity:500W(optional) Ambient Temperature:-20℃~55℃ IP Grade:IP65 |
|
Radiator |
Working Pressure:2bar-40bar Specification: 2Kw-400Kw |
|
|
Power supply |
AC Input: |
110-240V, 50/60Hz |
|
Operating system(optional) |
Standalone version |
RAM:8G SD play |
|
Android version |
Quad core cortex A8, All winner A31 ,1.2GHz 1G DDR3, android 4.4.2 or above. |
|
|
Windows pc |
Quad-core pc / i3 / i5 / i7 intel core |
|
|
Appearance |
Color option: |
Silver, white, black or optional |
|
Enclosure material |
Zinc coated steel+front tempered glass |
|
|
Installation: |
Wall mounting/roof hanging/floor standing |
|
|
I/O interface: |
1*USB,1* SD/MMC/MS card slot , |
|
