21.5 Inch Wall Mount Iphone Design 300nits Capacitive Multi Touch Screen Lcd Display Monitor With VGA HDMI Ports
Main Features :
1), Metal Case Enclosure Design.
2), Cost effective price with high quality LED Screen.
3), with 10 points capacitive Touchscreen
4), Support media contents like video,pictures,flashes etc.
5), Intelligent operation system, easy and fast operation.
6), Support for remote network control.
7), All-in-one, to meet diverse application requirements.
8), Independent research and development of hardware and software.
| Product Specification | ||
| Panel Details | Panel Brand | Samsung/LG/AUTO/ LCD/LED/Chimee |
| Interface | Interface | VGA + HDMI + DVI input |
| Touch Screen | option 1 | IR touch ( 2- 16 points ) |
| option 2 | capacitive touch (10 points ) | |
| Camera | optional | |
| Printer | optional | |
| Optional Functions: speakers, open frame | ||
| Features | ||
| 1. Application fields:public places ,for example,shopping mall, restaurant,airport, square, commercial buidings,etc. | ||
| 2. Outer shell is made of extra good quality metal material and tempered glass. | ||
| 3. It can connect to computer or player. | ||
| 4. Adopts high transparent tempered glass (2-6 mm ) as protection layer toprevent screen from being broken or distorted. | ||
Product Specifications of LCD Advertising Player
| Model |
ZXT-WTM 19BA(N)04 |
ZXT-WTM 22BA(N)04 |
ZXT-WTM 24BA(N)04 |
ZXT-WTM 43BA(N)04 |
ZXT-WTM 55BA(N)04 |
ZXT-WTM 65BA(N)04 |
| Brightness | 250 cd/m2 | 250 cd/m2 | 250 cd/m2 | 250 cd/m2 | 400 cd/m2 | 450 cd/m2 |
|
Display Area (mm) |
408(H)x255(V) | 477(H)x268(V) | 544(H)x303(V) | 941(H)x529(V) | 1074(H)×604(V) | 1209(H)x680(V) |
| Power Consumption | 25W | 30W | 35W | 80W | 110W | 170W |
| Response Time | 6ms | 8ms | 8ms | 5ms | 5ms | 5ms |
|
Contrast ratio |
1000:1 | 1000:1 | 1000:1 | 3000:1 | 3500:1 | 4000:1 |
| Resolution | 1920 x 1080 1080P | |||||
|
Visual angle L/R |
178°/178° | |||||
| Operating Voltage | AC 100V-240V, 50/60 Hz | |||||
| Installation Version |
Horizontal & Vertical |
|||||
|
Safty protection |
Safty Lock Design |
|||||
| Working Temperature |
0℃-40℃ |
|||||
| Storage Temperature |
-20℃-60℃ |
|||||
| Operation System | ||||||
| Operating System | Android 4.4(up to 5.1) | |||||
| CPU | 1.5GHz, Dual Core / 1.8GHz,Quad Core | |||||
| RAM | 1G,2G | |||||
| Internal Memory | NAND FLASH 4G | |||||
| Input | HDMI Input , VGA Input | |||||
| External Memory | SATA/USB/SD/CF card | |||||
Capacitive Touch Screen:
| Capacitive Touch Screen | Feature | USB Interface, Plug & Play, Free Driver | |||||||||||
| Tempered Glass 3mm | |||||||||||||
| Input Method | Finger , Capacitive Touch Pen | ||||||||||||
| Transparency | ≥85%±5% | ||||||||||||
| Compatible OS | WindowsXp,7,8,10,Linux,Mac,Android | ||||||||||||
| Connection Cable | FPC | ||||||||||||
| Active Force | ≤10g | ||||||||||||
| Structure | Glass+Glass | ||||||||||||
