High Definition CCTV LCD Monitor Widescreen Aluminum Alloy Long Life Span
Aluminum Alloy Desktop 21.5 Inch CCTV LCD Display Monitor 16:9 Widescreen 1080P
Product Feature :
1) Ultra-slim design, convenient use, delicate appearance .
2) Industrial A+ grade LCD panel .
3) High contrast, High brightness, vivid image layout, bets details performance .
4) Auto eliminate blur function, long life span .
5) Auto adjust VGA image reproduction rate .
6) Quick response time, no trailing effect .
6) Multiple date-image adjustment circuit, low image distortion .
7) Intelligence temperature control fan design, green and quiet .
8) Wide visual angle 178°, aspect ratio 16 : 9 .
9) Rich signal input, output interfaces, adapted in the different environments .
10) Appling the latest 3D digital image decode chipset, the latest DNR, image clear, clean and vivid .
11) Intensive the IR receiver, support the IR remote to modify the monitor parameters .
12) Build-in stable power, low consumption, long life span>60000hours .
| Model No. | ZXT-CLM2150A | |
| Panel | Size | 21.5”(16:9) |
| Type | LED | |
| Resolution | 1920x1080 | |
| Display area | 476(H)x268(V) | |
| Pixel pitch | 0.24825mmx0.24825mm | |
| Brightness | 250cd/m² | |
| Contrast | 1000:1 | |
| Response time | 5ms | |
| Viewing angle | 170°(H)x160°(V) | |
| Field frequency | 50HZ, 60HZ, 70HZ | |
| Color | Display color | 16.7M |
| Max color | Full Color | |
| Color system | PAL/NTSC | |
| Input/Output | CVBS input | BNCx2 |
| YPBPR input | 1(BNCx3) | |
| HDMI input | HDMIx1 | |
| VGA input | VGAx1 | |
| CVBS output | BNCx1 | |
| Audio | Audio input | RCAx2 |
| Power consumption | Power supply | AC100~240V,50/60HZ |
| Max consumption | ≤50W | |
| Standby | ≤1W | |
| Working environment | Temperature | 0℃~50℃ |
| Relative humidity | 10%~90% | |
| Storage environment | Temperature | -25℃~60℃ |
| Relative humidity | 5%~95% | |
| Dimension | Body dimension | 502mm(W)x298.6mm(H)x46mm(D) |
| Packing dimension | 570mm(W)x400mm(H)x140mm(D) | |
| Weight | N.W. | 5.5kg |
| G.W. | 6.5kg | |
| Installation | Installation method | Wall mounted, desktop optional |
| Others | Operation method | Panel buttons, IR remote control |
| Cooling system | Single fan cooling | |
| Casing material | Full metal casing | |
| Environment standards | All components and packing materials comply with international environment standards | |
| Accessories | User manual, warranty card, remote control, AC power cable | |
