43 inch IP65 waterproof information kiosk LCD advertising digital signage display totem

        With outdoor LCD systems we venture into higher level of engineering. These all-in-one systems have to cope with worst of outdoor environment effects and full-outdoors are exposed also to powerful effect of solar radiation (UV, visible light and IR), which presents main difference to semi-outdoor units. Bear in mind that solar radiation is so potent it can raise temperature far above ambient air temperature. operating in 30°C ambient air temperature will have on surface LCD temperature of 85°C. That is difference of 55°C, mostly caused by solar radiation, and certainly a fact nobody can afford to overlook.

        Semi outdoor systems on other hand are characterized by usage in outdoor areas without direct sun exposure, such as metro stations. These systems are more advanced than indoor, because of exposure to outdoor environmental factors, therefore needs thermal management (heating and cooling), high brightness/contrast performance LCD panel, vandal protection, cold and warm start procedures. It is relatively easy to engineer such systems as outdoor environmental factors are not as harsh as with full-outdoor. In most cases they will use simple ventilation and heating functionality. For a difference to full-outdoor displays, semi-outdoor units can utilize optical bonding technology as no direct solar radiation present. Outdoor enclosures (not all-in-one systems) do not have capacity to handle full-outdoor environment but can be used for semi-outdoor areas.

        Outdoor LCD vs. Indoor LCD When talking about digital signage public LCD displays we consider three general types: indoor, semi-outdoor and full-outdoor. Indoor systems are made for safe ?room temperature? areas not compromised by outdoor environment effects such as heat, cold, temperature fluctuation, dust, dirt, pollution, humidity, condensation, solar radiation, high ambient light and vandalism. They are relatively easy to be engineered and usually are operational less than 24 hours a day, presenting low load for integrated professional LCD panels or monitors. Big advantage of indoor systems, beside much wider choice of components and technology simplicity, is that in case of failure unit is safe until tech team arrives. Even though reliability should be important with any display it is not as critical as in case of outdoor systems.

FAQ

1. How do ZXT LCD ensure quality?

Our high quality standard is achieved with the following.

1.1 The process is strictly controlled under ISO 9001:2008 standards.
1.2 Extensive use of software in managing the production process
1.3 Stock up much screen panel in factory, and non-stop Power-on test for each LCD Panel with 72 hours.
1.4.Dedicated quality assurance team with failure case analysis process
1.5.Continuous staff training and education

2. How do ZXT LCD keep your price competitive?

Over the last decade, prices of many raw materials (e.g. copper, chemicals) had doubled, tripled or quadrupled; Chinese currency RMB had appreciated 31% over US dollar; And our labor cost also increased significantly.

However, ZXT LCD have kept our pricing steady. This owns entirely to our innovations in reducing cost, avoiding wastes and improving efficiency. Our prices are very competitive in the industry at the same quality level.

We believe in a win-win partnership with our customers. Our partnership will be mutually beneficial if we can provide you an edge on cost and quality.

3.  Which essential factor are needed confirmation for outdoor lcd display before get a accurate cost?

4.1 Accurate screen size: various screen size with different cost difference .
4.2 Any additional requirements need pay extra cost such as anti-glare glass requirements.

4.3 Quantity : we also accept sample for testing as trail order, For sample or few machine, we usually use wooden box or wooden frame to pack the goods to ensure the safety in the transport. So, the cost will be higher a little due to the extra package cost. If you order a big quantity, we can use container to ship the goods, no need extra wooden frame as outer package.

4. What’s the typical assemble process flow of outdoor lcd display?

Purchasing LCD Panel → Purchasing shell and electronic parts → Assemble → operating system installed → software installed →Testing 72 hours →record → Visual Inspection.
