High Precision Shot Blasting Machine Parts Anti Corrosive CE ISO Approved
Price:
Negotiable
MOQ:
1 set
Delivery Time:
In stocked
Brand:
Qingdao Puhua
Product Description
Product Description
Technique Parameter
| Direct-driven blast wheel | |||
| Q130 Series | Q034 Series | ||
| Type | Single disc,curved blade | Double discs,straight blade | |
| Impeller rotation direction | Single direction (left or right) | Single direction(left or right) | |
| Impeller and blade diameter(mm) | Φ333 | Φ390 | |
| Effective blade width(mm) | 55 | 80 | |
| Impeller speed(rpm) | 2930 | 2930 | |
| Ejection velocity(m/s) | 71 | 78 | |
| Abrasive flow rate(kg/min) | 7.5kw | 120 | 120 |
| 11kw | 180 | 180 | |
| 15kw | 250 | 250 | |
| 18.5kw | 310 | 310 | |
| 22kw | / | 360 | |
| Weight(excluding motor) | About 225kg | About 235kg | |
| Belt-driven blast wheel | |||
| Q130 Series | Q034 Series | ||
| Type | Single disc,curved blade | Double discs,straight blade | |
| Impeller rotation direction | Single direction (left or right) | Single direction (left or right) | |
| Impeller and blade diameter(mm) | Φ333 | Φ420 | |
| Effective blade width(mm) | 55 | 80 | |
| Impeller speed(rpm) | 2950 | 2600 | |
| Ejection velocity(m/s) | 71 | 74 | |
| Abrasive flow rate(kg/min) | 7.5kw | 120 | 120 |
| 11kw | 180 | 180 | |
| 15kw | 250 | 250 | |
| 18.5kw | 310 | 310 | |
| 22kw | / | 360 | |
| Weight(excluding motor) | About 280kg | About 210kg | |
