GB/T 3087 10# Seamless Steel Tubes For Low And Medium Pressure Boilers
GB/T 3087 10# 20# Seamless Steel Tubes For Low And Medium Pressure Boilers
Introduction
GB/T 3087 is a Chinese standard that specifies the requirements for seamless steel tubes used in low and medium pressure boilers. These tubes are designed to withstand the pressure and temperature conditions found in such boilers. This article provides an overview of the material, specification, key features, chemical composition, mechanical properties, steel grades, applications, and possible alternative grades for GB/T 3087 10# and 20# seamless steel tubes.
Material and Specification
GB/T 3087 10# and 20# seamless steel tubes are made from carbon structural steel. The material composition and mechanical properties of these tubes are regulated by the standard to ensure their suitability for low and medium pressure boiler applications. The tubes are manufactured using a seamless process, which ensures their strength and reliability.
Key Features
The key features of GB/T 3087 10# and 20# seamless steel tubes include:
- High strength: These tubes are made from carbon structural steel, which provides excellent strength and durability.
- Seamless construction: The seamless manufacturing process ensures the absence of welds, making the tubes less prone to leakage and failure.
- Suitable for low and medium pressure boilers: These tubes are specifically designed to withstand the pressure and temperature conditions found in low and medium pressure boilers.
- Wide range of applications: GB/T 3087 10# and 20# seamless steel tubes are used in various industries, including power generation, petrochemical, and manufacturing.
Chemical Composition
| Element | 10# Seamless Steel Tubes | 20# Seamless Steel Tubes |
|---|---|---|
| Carbon (C) | 0.07-0.14% | 0.17-0.24% |
| Silicon (Si) | 0.17-0.37% | 0.17-0.37% |
| Manganese (Mn) | 0.35-0.65% | 0.35-0.65% |
| Phosphorus (P) | ≤0.035% | ≤0.035% |
| Sulfur (S) | ≤0.035% | ≤0.035% |
Mechanical Properties
| Property | 10# Seamless Steel Tubes | 20# Seamless Steel Tubes |
|---|---|---|
| Tensile Strength (MPa) | 335-475 | 410-550 |
| Yield Strength (MPa) | ≥205 | ≥245 |
| Elongation (%) | ≥24 | ≥20 |
| Hardness (HB) | ≤179 | ≤197 |
Steel Grade
The steel grades specified in GB/T 3087 for seamless steel tubes are 10# and 20#. These grades indicate the carbon content and mechanical properties of the tubes. The choice of steel grade depends on the specific requirements of the application.
Application
GB/T 3087 10# and 20# seamless steel tubes are widely used in low and medium pressure boilers. They are also utilized in various industries where high strength and resistance to pressure and temperature are required. Some common applications include:
- Power generation plants
- Petrochemical industry
- Manufacturing industry
Possible Alternative Grades
While GB/T 3087 10# and 20# seamless steel tubes are widely used, there are alternative grades available that may suit specific requirements. Some possible alternative grades include ASTM A106 Grade B, DIN 17175 St35.8, and JIS G3454 STPG370. These alternative grades should be carefully evaluated based on their chemical composition, mechanical properties, and suitability for the intended application.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
