High Efficiency Organ Filter Paper for Paint and Painting Room
Paint Stop Spray Booth Exhaust Filter Fiberglass Floor Filter Made
Product Description
Organ painting filter is good for spray painting. It belongs to the foldaway. Organ filters efficiency will increase along with the saturations increase. This is a different from the fibre filter media. The fibre filter medias efficiency will descend along with saturations increases. The efficiency will up to 98%.
Widely used in kinds of painting lines like electrical equipment, toy, athletic equipment, automobile manufacture and maintenance.
Features
1. Low wind resistance, high performance, low cost;
2. Beyond the service life of other filters, up to 6 times;
3. Large adsorption capacity, up to 13kg/m2;
4 The filtration efficiency can be up to 99.9% depending on the type, characteristics and solid content of the coating.
Technical Data Sheet
Dimension(L x W x H): 1.0m x 10m; 1.2m x 10m; 0.9m x 10m
Construction: Paper Filter Media
Medium Material: Kraft Paper
Avg.Arrestance: ≥75%(Ashrae52.1-1992)
Flammability Rating: K1(DIN 53438)
Adsorption Capacity: 13kg/M2
Specification: 1.0m x 10m; 1.2m x 10m
Parameters Table
| Type | Size (m) | Pleated distance (mm) | Initial Pressure (Pa) | Final pressure (Pa) | Temperature resistance | Adsorption capacity |
| AR-WXZ-A | 1 x 10 | 5 | ≤70 | 150 | ≤100ºC | 13kg/m2 |
| AR-WXZ-AA | 1.2 x 10 | 5 | ≤70 | 150 | ≤100ºC | 13kg/m2 |
| AR-WXZ-AAA | 0.9 x 10 | 5 | ≤70 | 150 | ≤100ºC | 13kg/m2 |
| Note: Other specifications are available on request | ||||||
