10.1 Inch HDMI VGA Resistive Touch Display 1000 CD/M Outdoor DC 12V

Price Negotiable

Price: Negotiable

MOQ: 1 Piece

Brand: SHINHO

Product Description

10.1 Inch HDMI VGA Resistive Touch Screen Monitor 1000 CD/M Outdoor DC 12V

Features

This 10.1 inch TFT LCD Display is an ideal choice for outdoor kiosk. It's 1000cd/m high bright, sunlight visible for outdoor use. We adopt industrial grade LCD panel, which can operate in a wide temperature range -10 to 60°C. We are specialized in customization. Contact us to get a custom design to perfect match your requirements.

Advantages

10.1 inch industrial grade LCD panel
5 Wire resistive touchscreen
Front panel IP65 water resistant
1000cd/m sunlight readable
HDMI, VGA, DVI, USB interface
Suitable for outdoor kiosk

Application

Outdoor kiosk

high-speed rail station

petrol station

vending machine

gas station

Self-service storage cabinet

outdoor inspection equipment

security Turnstile

Auto payment machine

Specifications

Model:SL101
LCD panel
Panel size	10.1"
Resolution	1280*800
Aspect ratio	16:10
Support Color	16.7M colors
Brightness (cd/m²)	1000cd/m high brightness
Contrast ratio	800:1
View angle	85°/85°/85°/85° (R/L/U/D)
Touch panel
Touchscreen Type	5 wires restive touch
Surface Hardness	3H
Luminousness	90%
Touch Interface	USB (RS232 optional)
Touch response time	2ms
Working Life	>35 million times
Touch options	(10 points Project Capacitive Touch, IR touch optional)
Signal Ports
VGA	1x VGA
DVI	1x DVI
HDMI	1x HDMI
Audio in/out	optional
OSD
OSD control	Brightness, contrast ratio, auto adjustment, H/V position, language select, etc.
Support languages	English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc.
Support OS	Windows XP, Windows /7/8/10, Linux, Mac OS X, Android, ect.
Power Supply
External Power Supply	AC 100 - 240V, 50-60Hz
Working voltage	DC 12V
Power consumption	≤35W
Enclosure
Material	aluminium alloy bezel+High strength cold rolled steel back case
Color	Black, white, Silver, color can be customized
VESA mounting	75×75mm
IP grade	Front panel IP65 waterproof
Operating Environment
Temperature Range	operating: -10 to 60°C, storage: -20 to 80°C
Relative humidity	operating: 10% to 80%, storage: 5% to 90%
Packing Details
Net weight	1.7kg
Gross weight	2.5kg
Product Dimension	28.49×20.09×3.4cm
Packing size	33×30×10cm
Accessories	Power adapter, USB touch cable, HDMI cable, embedded screws
Other
	embedded mounting
mounting	wall mounting brackets (optional)
mounting	desk stand holder (optional)
Warranty	1 year warranty
Certificates	CE, FCC, RoHS
