12 Volts 10 Amps Smart Battery Charger High Frequency For Li / Lead Acid Battery

12 Volts 10 Amps Smart Battery Charger High Frequency For Li / Lead Acid Battery

Brief Description:

Portable battery charger 12 volts 10 amps with aluminum housing and small size. Input with worldwide 110 - 240 Vac. Max charigng voltage is 14.4V or 14.7V for lithium (LiFePO4, Li - ion, Li Polymer, LiMO2) or lead acid (SLA, AGM, Deep cycle, Flooded, GEL). Automatic four steps charging with pre - charge, CC, CV and floating / shut - off. This smart 12V charger can detect your battery state automatically and then charge it automatically accordingly, protect your battery life to maximum.

Features


1) Optional charging methods: Lithium or lead acid batteries.
2) Advanced high frequency switching mode power supply technology.
3) DC output isolated from AC input.
4) Automatic worldwide Input 110/230Vac(90~264Vac), 50Hz~60Hz.
5) Charging parameters are insensitive to the AC input line voltage variations.
6) Completely automatic 4 steps charge: pre-charge, CC, CV, floating/trickle or shut-off.
7) Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.
8) Aluminum casing, light weight, portable.
9) 100% full load burn-in test.
10) 2 years warranty.

Technical Specs.:

1) Dimensions(LxWxH): 170 x 90 x 50 MM
2) Net weight: 1.2 KG
3) Max charging voltage(CV): 14.6 / 14.7 volt
4) Floating voltage: customized
5) Max output current (CC): 10 amps
6) Charging method: pre-charge, CC, CV, floating / trickle or shut off
7) AC input voltage: 110 - 240Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: customized by user’s country
10) Output connector type: customized by applications
11) Enclosure: Aluminum
