12.6V 10A Lithium Ion Battery Charger Automatic CC CV Fast Charging Small Aluminium Case
12.6V 10A Lithium ion Battery Charger, automatic CC CV fast charging, small aluminium case only 1 kg
Brief Descriptions:
12.6V 10Amps intelligent battery charger is designed for lithium-ion battery, input with worldwide 110 to 230Vac. Smart max charging voltage is 12.6V for 3S 4.2V/cell Li-ion batteries. Intelligent 4 steps charging with pre-charge, CC, CV and automatic cut-off, this charger will charge your batteries with very fast speed, with high efficiency and protect your battery life. Aluminum housing, light weight and portable.
Specifications:
Input voltage: 110-240Vac
Output-rated: 10Vdc, 10Amps
Max charging voltage: 12.6Vdc
Size: 170*90*50 mm
Net weight: 1 KG
Color option: Silver or Black.
Features:
◆ Advanced high frequency switching mode power supply technology.
◆ DC output isolated from AC input.
◆ Auto worldwide Input 110 / 230Vac(90 ~ 264Vac), 50Hz~60Hz.
◆ Charging parameters are insensitive to the AC input line voltage variations.
◆ Completely automatic battery charging: Pre-charging, CC, CV, Absorption, Float or Cut-off.
◆ 2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..
◆ Possibility to customize charging curve for request.
◆ Protections: Short circuit, Over-voltage, Over-temperature, Reverse Polarity.
◆ Efficiency > 95%.
◆ Forced ventilation with fans.
◆ 100% full load burn-in test.
◆ Aluminum casing, light weight, portable.
| Output series: 240W Size: 170×90×50 mm Net weight: 1.0 KG | ||||||
| Input | Model | Apply to battery types | Floating V | CV (V) | CC (A) | Switching |
|
AC Input: 85~264V
Frequency: 47~63HZ
|
VL1210L | 12V LiFePO4 Battery | 14.6V | 10A | CC5~8% | |
| VL1210 | 12V Lead-acid Battery | 13.5V | 14.7V | 10A | CC20% | |
| VL2407LM | 24V Li-MnO2 Battery | 29.4V | 7A | CC5~8% | ||
| VL2407L | 24V LiFePO4 Battery | 29.2V | 7A | CC5~8% | ||
| VL2407 | 24V Lead-acid Battery | 27.6V | 29.4V | 7A | CC20% | |
| VL3605LM | 36V Li-MnO2 Battery | 42V | 5A | CC5~8% | ||
| VL3605L | 36V LiFePO4 Battery | 43.8V | 5A | CC5~8% | ||
| VL3605 | 36V Lead-acid Battery | 41.4V | 44.1V | 5A | CC20% | |
| VL4804LM | 48V Li-MnO2 Battery | 54.6V | 4A | CC5~8% | ||
| VL4804L | 48V LiFePO4 Battery | 43.8V | 4A | CC5~8% | ||
| VL4804 | 48V Lead-acid Battery | 55.2V | 58.8V | 4A | CC20% | |
| VL6003L | 60V LiFePO4 Battery | 73V | 3A | CC5~8% | ||
| VL6003 | 60V Lead-acid Battery | 67.5V | 73.5V | 3A | CC20% | |
| VL72025L | 72V LiFePO4 Battery | 87.6V | 2.5A | CC5~8% | ||
| VL72025 | 72V Lead-acid Battery | 81V | 88.2V | 2.5A | CC20% | |
| Note: customized input / output / plug type / connectors are available. | ||||||
