Portable 54.6V 20A Lithium Ion Battery Charger with Aluminum Case 1200W Output Power
54.6V 20A Lithium ion Battery Charger, Smart and Portable with Aluminum Case, 1200W Output Power
Brief Description:
High power 1200W max 54.6 volts 20 amps automatic battery charger for lithium ion battery pack.
Input voltage: 110 or 240 Vac.
It is designed for electric motorcycles, electric floor sweepers and electric cars, smart charge LiFePO4 / Li ion / LiMO2 batteries.
Charging with 54.6 Vdc or 58.4 Vdc 20 amps, max 1200 watts output power.
Smart 4 steps charging: pre charge, CC, CV and automatic shut off.
Small size, portable for electric scooters, electric bikes and electric motorcycles.
We can customize input and output by your battery specifications.
Features:
Advanced high frequency switching mode power supply technology.
DC output isolated from AC input.
Input 110 / 230Vac, 50Hz ~ 60Hz.
Charging parameters are insensitive to the AC input line voltage variations.
Completely automatic battery charging: Pre charging, CC, CV, Absorption, Float or Cut - off.
2 LEDs: LED1 Red (power on), LED2 Red / green (charging/full)..
Possibility to customize charging curve for request.
Protections: short circuit, over voltage, over temperature, reverse Polarity.
Efficiency > 95%.
Forced ventilation with fans.
100% full load burn-in test.
Aluminum casing, light weight, portable.
Technical Specs.:
1) Dimensions(LxWxH): 260 x 150 x 90 mm
2) Net weight: 5.5 KG
3) Max charging voltage(CV): 54.6 / 58.4 volt
4) Floating voltage: customized
5) Max output current (CC): 20 amps
6) Charging method: automatic pre-charge, CC, CV, floating / trickle or shut off
7) AC input voltage: 110 or 240Vac
8) AC input freq.: 50 / 60 Hz
9) AC plug: customized by user’s country
10) Output connector type: customized by applications
11) Enclosure: Aluminum
| Output series: 1,200W Size: 260×150×90 mm Net weight: 5.0 KG | ||||||
| Input | Model | Apply to battery types | Floating V | CV (V) | CC (A) | Switching |
|
AC Input: 110 / 230V
Frequency: 47~63HZ
|
VL1250L | 12V LiFePO4 Battery | 14.6V | 50A | CC5~8% | |
| VL1250 | 12V Lead-acid Battery | 13.5V | 14.7V | 50A | CC20% | |
| VL1450 | 14V AGM Battery | 13.5V | 14.4V | 50A | CC20% | |
| VL1650L | 16V LiFePO4 Battery | 18.2V | 50A | CC5~8% | ||
| VL2435LM | 24V Li-MnO2 Battery | 29.4V | 35A | CC5~8% | ||
| VL2435L | 24V LiFePO4 Battery | 29.2V | 35A | CC5~8% | ||
| VL2435 | 24V Lead-acid Battery | 27.6V | 29.4V | 35A | CC20% | |
| VL3625LM | 36V Li-MnO2 Battery | 42V | 25A | CC5~8% | ||
| VL3625L | 36V LiFePO4 Battery | 43.8V | 25A | CC5~8% | ||
| VL3625 | 36V Lead-acid Battery | 41.4V | 44.1V | 25A | CC20% | |
| VL4820LM | 48V Li-MnO2 Battery | 54.6V | 20A | CC5~8% | ||
| VL4820L | 48V LiFePO4 Battery | 43.8V | 20A | CC5~8% | ||
| VL4820 | 48V Lead-acid Battery | 55.2V | 58.8V | 20A | CC20% | |
| VL6015L | 60V LiFePO4 Battery | 73V | 15A | CC5~8% | ||
| VL6015 | 60V Lead-acid Battery | 67.5V | 73.5V | 15A | CC20% | |
| VL7212L | 72V LiFePO4 Battery | 87.6V | 12A | CC5~8% | ||
| VL7212 | 72V Lead-acid Battery | 81V | 88.2V | 12A | CC20% | |
| VL8410L | 84V LiFePO4 Battery | 102.2V | 10A | CC5~8% | ||
| VL8410 | 84V Lead-acid Battery | 94.5V | 102.9V | 10A | CC20% | |
| VL9609L | 96V LiFePO4 Battery | 116.8V | 9A | CC5~8% | ||
| VL9609 | 96V Lead-acid Battery | 108V | 117.6V | 9A | CC20% | |
| Note: customized input / output / plug type / connectors are available. | ||||||
Additional information
DANL New Energy is a 15 years battery chargers manufacturer / factory / supplier. We design and manufacture all by ourselves. We control the quality with high level and have been updating our technology to the latest. We promise 2 years full warranty for all of our battery chargers. Best quality and factory price are worth to be your sincere supplier of battery charger market.
