Silk Colour Measurement Device Colorimeter Spectrophotometer Food Food
Price:
Please send inquiry
MOQ:
1 Unit
Delivery Time:
2-5 work days
Brand:
Silk
Product Description
Color Test Chroma Meter Spectrophotometer Silk NS800 with 45°/0 Optical Geometry and 0.04 Repeatibility
NS800 color spectrophotometer is developed by Silk with independent intellectual property rights.It uses 45/0 geometrical optical structure, comply with CIE No.15, GB/T 3978. With human body engineering mechanics and humanized operation design, NS800 color spectrophotometer has stable performance precise measurement and powerful functions in the leading position of the same industry.
Technical Specification
| Parameters | Spectrophotometer NS800 |
| Optical Geometry | 45°/0 |
| Inte-grating Sphere Size | Φ58mm |
| Measuring Aperture | Φ8mm |
| Repeatibility | ΔE*≤0.04 |
| Inter-instrument Agreement | ΔE*≤0.2 |
| Observer Angle | 2° & 10° |
| Wavelength Range | 400-700nm |
| Wavelength Pitch | 10nm |
| Reflectance Range | 0-200% |
| Color Space | CIE LAB, XYZ, Yxy, LCh, CIE LUV |
| Color Difference Formula | ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v |
| Displayed Data | Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation |
| Other Chromaticity Data | WI(ASTM E313, CIE/ISO, AATCC, Hunter), YI(ASTM D1925, ASTM 313), TI(ASTM E313, CIE/ISO), Metamerism Index (Mt), Color Strength, Color Stain, Color Fastness |
| Illuminant | D65, D50, A, C, D55, D75, F2, F6, F7, F8, F10, F11, F12 |
| Illuminant Device | Combined LED Light |
| Illuminant Lifespan | 5 years, More than 1.6 million measurements |
| Sensor | Silicon Photoelectric Diode Array |
| Data Storage | 1000 Standards, 15000 Samples |
| Data Port | USB |
| Display Size | TFT 3.5" |
| Touch-Screen | Yes |
| Working Temperature | 0~40℃(32~104℉) |
| Storage Temperature | -20~50℃(-4~122℉) |
| PC Software | SQC8 |
| Weight | 600g |
| Dimension | 90*77*230mm |
| Battery | 3200mAh Large Capacity Li-ion Battery |
| Standard Accessory | Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM(containing color management software), USB Cable, White and Black Calibration Cavity, Protective Cover and Wrist Strap. |
| Optional Accessory | Universal Test Components, Micro Printer, Powder Test Box |
Applications:
Silk colorimeter spectrophotometer is widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, medical, cosmetic industries, scientific research institutes, schools and laboratories. It can measure reflectance spectrum and other color index precisely. NS800 color spectrophotometer not only can help to perform color matching and color management studies, but also can control product quality management. Silk colorimeter is equipped with high-end color management software that can connect to PC to achieve more extension functions.
