CIE Lab Portable Silk Colorimeter Chroma Meter For Color Measurement
Silk NH310 portable colorimeter CIE lab color paces Φ8mm & Φ4mm apertures chroma meter
NH310 portable colorimeter is a mainstream brand colorimeter introduced by Silk which has synthesized the advantages of ten more traditional imported colorimeters and has experienced ten thousands tests and applied many innovative technologies.
With 8mm and 4mm two measurement apertures, NH310 colorimeter is the most popular portable colorimeter used in fabrics, paper, plastic parts, building materials. Double locating (Camera locating and Illumination locating) helps measure kinds of different shape samples, such as small size, or curve. The standard configuration software CSCQ3 is able to perform color difference analysis, color difference cumulative analysis, chromaticity index, color sample database management, simulating object color, etc.
Technical Specification
| Parameters | Colorimeter NH310 |
| Optical Geometry | 8°/d |
| Measuring Aperture | Φ8mm & Φ4mm |
| Repeatibility | ΔE*≤0.06 |
| Inter-instrument Agreement | ΔE*≤0.4 |
| Measurement Range | L: 0-100 |
| Observer Angle | CIE 10° |
| Illuminant | D65, D50, A |
| Illuminant Device | Combined LED Light |
| Illuminant Lifespan | 5 years, More than 1.6 million measurements |
| Sensor | Silicon Photoelectric Diode Array |
| Data Storage | 100 Standards, 2000 Samples |
| Data Port | USB |
| Display Size | TFT 2.7" |
| PC Software | CQCS3 |
| Weight | 500g |
| Dimension | 205*70*100mm |
| Battery | 3200mAh Large Capacity Li-ion Battery |
Color Space
| Color Space | CIE LAB, CIE XYZ, CIE RGB, CIE LCh, CIE L*u*v |
| Color Difference Formula | ΔE*ab, ΔE*Ch, ΔE*CIE94, ΔE*Lab, ΔE*Hunter |
| Displayed Data | Colorimetric Value, PASS/FAIL Result, Color Offset |
| Other Chromaticity Data | White Index |
Accessory
| Standard Accessory | Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM(containing color management software), USB Cable, White and Black Calibration Cavity, Protective Cover. |
| Optional Accessory | Universal Test Components, Micro Printer, Powder Test Box |
Application Industry
Nowadays, color management instruments, like spectrophotometers, colorimeters, have been widely applied to industries like painting, lacquer, ink, coating, leather, paper, printing, plastics, electronics, furnitures, wood, decorating, ceramics, tiles, metals, hardware, marble, electroplating, package, food, cosmetics, pharmacy, cloth, garments, textiles and traffic signage, etc. And also, schools and laboratories need the color measuring instruments to teach and study.
