NR60CP Portable Spectrophotometer Colorimeter , PVC Packaging Color Difference Meter

Price Negotiable
Price: Please send inquiry
MOQ: 1 Unit
Delivery Time: 2-5 work days
Brand: Silk
Product Description

PVC packaging color difference meter Silk NR60CP economic colorimeter with 8mm&4mm two apertures



Easy Operation Color Colorimeter High Precise and High Stable Portable Colorimeter
Product Instroduction


Certificates: ISO9001:2008; CE; FCC; ROHS; TUV.



NR60CP multiparameter colorimeters manufacturers with 8mm/4mm aperture has the advantages of high accuracy, powerful function and precise measurement which are warmly welcomed by customers.


NR60CP colorimeter is a multifunctional colorimeter with high quality and competitive price. Silk insists on independent research whose technology innovation is unique in color management field.

NR60CP desiccated coconut colorimeter with 8mm/4mm Measurement Aperture



Specifications



Illuminating/Viewing Geometry: 8°/ d
Light Source: LED Light
Sensor: silicon photodiode array
Measuring aperture: Φ8mmflat aperture; Φ4mmtip aperture
Color Space: CI E L AB,XYZ,LCh,CI E RGB,CI E LUV
Color Difference Formula: ΔE* ab, ΔE( h) , ΔE* uv,ΔE* 94, ΔE*cmc ( 2: 1) , ΔE*cmc ( 1: 1) , ΔE* 00
Other Chromaticity Data: WI ( E313,CI E, AATCC,Hunt er ),YI ( D1925,313),Color Fastness, Staining Fastness, J PC79,BFD( 1. 5: 1),FMCI I
Observer: CI E 10°
Illuminant: D65,A,C,D50,F2,F6,F7,F8,F10,F11,F12
Display Data: Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset,
Measuring Time: 0. 4s
Repeatability: ΔE* ab 0. 03 (Average of 30 measurements of standard white plate within 5s)
Errors between each instrument: within Delta E*ab 0.2
Dimension: 205*67*80mm
Weight: 500g
Battery: rechargeable lithium-ion battery 3. 7V @ 3200mAh
Lamp Life: 5 years, more than 1.6 million measurements
Screen: TFT 2.8 inch(16: 9)
Interface: USB/ RS- 232
Storage: 100 Standards, 20000 Samples
Operating Temperature: 0~40℃(32~104°F)
Storage temperature: -20~50℃(-4~122°F)
PC software: CQCS3 software
Optional accessory: miniature thermal printer, powder test box





Features



1. Switchable 8mm and 4mm measuring apertures, easy to measure concave surface.
2. Higher measurement stability and accuracy, Delta E ab<0.03.
3. More color spaces, various color indexes, extensive applicability.
4. Double locating: illuminating locating and cross locating
5. Configured with high-capacity rechargeable Li-ion battery
6. Built-in white plate parameters and physical white calibration board, easy to operate;
7. New integrating sphere optical path design, more stable measurement;
8. Measurement data can pass national metrology authentication.



Application



Silk colorimeter spectrophotometers are widely used to compare color difference in plastic, electronic, painting, coating, ink, texile, garment, printing, dyeing, food, medical, cosmetic industries and institutes, schools and laboratoris.



Colorimeter Spectrophotometer Application



Company Information
company



Silk. is a high-tech enterprise. We research, develop, produce and market photoelectric detection products in photoelectric detection technology field and color management field.





The parameters of test results are integrating with international standards. Our Silk brand colorimeter spectrophotometer products are exported around the world. We can provide customization service which has been well received by customers.



Product Details
Colorimeter Spectrophotometer Certifications
certificate 1
Warranty



All our products have one year warranty from the purchase date. If it has something wrong during warranty, you can send it back to us. The buyer pays for the returning shipping cost and we will pay for the sending shipping cost.



Related Knowledge about Spectrophotometer



Color Space


CIE LAB
-L(Lightness)-0 is black,100 is white
-a(Red-Green)-positive values are red; negative values are green and 0 is neutral
-b(Blue-Yellow)-positive values are yellow;negative values are blue abd 0 is neutral

CIE LCH
L: Lightness,value is the same in each scale C:Chroma H:Hue Angle

dE Total Color difference
Delta-E is a measurement used to indicate how much a color deviates from an accepted standards.The higher the dE, the more inaccurate the color.
