Portable 4mm 8mm Silk Colorimeter Precision Spectrophotometer NH310 Auto Calibration
NH310 High precision portable 4mm 8mm colorimeter precision spectrophotometer
Brief Introduce:
NH310 high quality portable color difference meter:
Integrating the advantages of dozens of traditional color difference meter launched after the mainstream brand color difference meter, after tens of thousands of tests, and the application of many innovative technology, accurate, stable, beautiful and affordable.
Suitable for many occasions of color detection and control, is the service factory, chemical plant, printing plant, automobile factory, metal processing plant, mold factory, coating factory and other production in the color management of the best choice.
Specification:
| Model | NH310 |
| Display Mode/Color Space | CIE L*a*b; CIE XYZ; CIE RGB;CIEL*u*v; CIE*C*H; Whiteness &Yellowness; Color Fastness |
| Color Difference Formula | ΔE*ab; ΔL*ab; ΔE*C*H; ΔECIE94; ΔEHunter |
| Illuminating/viewing geometry | 8/d (8°illumination angle/diffuse viewing) |
| Light Source | LED blue light excitation |
| Detector | Silicon photoelectric diode |
| Measuring Aperture | Φ8mm; Φ4mm; Φ8mm extended aperture (optional) |
| Measuring Conditions | Observer: CIE 10° Standard Observer Illuminant: CIE Standard Illuminant D65; D50; A |
| Measuring Range | L: 0 to 100 |
| Repeatability | Standard deviation within ΔE*ab 0.06 (Measurement Conditions: Average of 30 measurements of standard white plate) |
| Minimum Interval Between Measurement | Approx. 1 sec |
| Battery Life | More than 3000 measurements |
| Lamp Life | more than 1.6 million times in 5 years |
| Display | TFT True-color; 2.8 inch@(16:9) |
| Interface | Model B: USB RS-232: Baud rate 19200bps |
| Operating Temperature Range | -10℃ to 40℃ |
| Storage Temperature | -20℃ to 50℃ |
| Humidity Range | less than 85% relative humidity, no condensation |
| Weight | 500g |
| Dimensions | 205 x 70 x 100 mm |
| Size of the Packing | 435 x 205 x 345mm |
| Standard Accessories | AC Adapter; Li-ion Battery; Operation Manual; Software CD; USB Cable; White Calibration Cover; Φ8mm and Φ4mm Measuring Aperture |
| Optional Accessories |
extended aperture(Φ8mm); Mini-printer; Printer Cable; Powder Test Box; Universal Test Components |
FAQ:
Q1: What's about the paypment term?
A1: We accept trade assurance,western union ,Visa master card and tt. Trade assurance
can protect you, when you confirm the product then the money into my account.
Q2 Do your product have warranty?
A2 Yes,all our products enjoy one year warranty protect.
Q3 When do you send the products? And how do you send it ?
A3 For the sample or small order, we will send out the goods with 2 days,If have stock ,we will send immediately. We send them by ups,fedex,tnt or dhl.For big order,normal is 20 days will finish.
Q4 Are you trading company or factory?
A4 We are factory,all selling products we make them by ourself.
Price will direly to the bottom and guaranty the quality.
Q5 Do you accept OEM or revised logo,color,model,size?
A5 Yes,we accept OEM for the qualify buyer.We can make the products according to customer personal requirement.
