ESSER T06 Geometry Camera Lens Test Chart Silk YE006 Checkerboard Distortion Test Target

Price Negotiable

Price: Please send inquiry

MOQ: 1 Pcs

Delivery Time: 1-4 Days

Brand: Silk - SineImage

Product Description

Model	YE006/T06
Type	Reflective/Transparent
Size	280 x 210mm(A280&D240)
Ratio	4:3

Specification

The chessboard test chart checkerboard Distortion Test Target T06 for checking geometry and resolution is designed for checking geometry and resolution.

Data

Similar to a chessboard the test charts is composed of 13 x 18 black and white square fields which are surrounded by rectangular fields at the edges that correspond to the 14/19 grid raster lines of electronic test generators. (The division of the horizontal grid lines of these generators corresponds to 42 lines per complete picture.)

Utilization

• Checking geometry and the congruency of raster, by means of an electronically generated grid, if necessary

• Checking the uniformity of the signal generation

Standard Transparent/Reflectance Test Chart Size
Size	Picture size(4:3)	Picture size(16:9)	Chart Size(16:9)
A280	280*210mm	280*157.5mm	365*305mm
D240	240*180mm	240*135mm	320*290mm
D280	280*210mm	80*157.5mm	360*280mm

ISO 12233 Resolution Test Chart Size
Model	Specification	Size	Material
NQ-10-50A	0.5X	10x17.8 cm	photographic paper
NQ-10-100A	1X	20x35.6 cm	photographic paper
NQ-10-200A	2X	40x71.1 cm	photographic paper
NQ-10-400A	4X	80x142.2 cm	photographic paper
NQ-10-800A	8X	160x284.4 cm	photographic paper
