4mm Aperture CIE Lab Precision Colorimeter Silk NR110
Precision Colorimeter Silk NR110 with 4mm aperture CIE lab color space
1 4mm aperture
2 Accuracy: delta E 0.08
3 Illuminant: D65
4 Li-ion battery
Silk Brand Color Meter / Colorimeter Price Manufactuer Features
1. Double Locating: Illuminating locating and cross locating
2. Double Measurement End Face: Large area measurement and small area measurement
3. New Integrating Sphere Design: More stable measurement
4. Equipped with Rechargeable High-Capacity Li-ion Battery
Silk Brand Color Meter / Colorimeter Price Manufactuer Specifications
| Illuminating/Viewing Geometry | 8/d |
| Measuring Aperture | Φ4mm |
| Detector | Silicon photoelectric diode |
| Locating | Illuminating Locating/Cross Locating |
| Measurement End Face | Large stable end-face and small concave-convex end-face |
| Color Space |
CIEL*a*b*C*h* CIEL*a*b* CIEXYZ |
| Color Difference Formula | delta E*ab delta L*a*b* E*C*h* |
| Light Source | D65 |
| Light Source Device | LED blue light excitation |
| Errors Between Each Equipment | ≤0.80 delta E*ab |
| Storage | 100pcs standards 20000pcs samples |
| Repeatability |
Standard deviation within E*ab 0.08 Average of 30 measurements of standard white plate |
| Language | English/Chinese |
| Weight | 450g |
| Dimension | 205×67×80 mm |
| Power source | Rechargeable lithium-ion battery 3.7V@3200mAh |
| Lamp Life | 3 years, more than 1.6 million measurements |
| Charging Time | 8 hours--100% electricity |
| PC Software | CQCS3 Software |
| Printer (optional) | Miniature thermal printer |
Silk Brand Color Meter / Colorimeter Price Manufactuer
Illuminating Locating, Cross Locating, Large Stable End Face, Small Concave-Convex End Face. (for NR110 Precise Colorimeter )
ISO 9001, CE, ROHS, FCC, TUV, SCM CERTIFICATES
Silk & Silk is a very professional manufacturer from China for 22 years, and mainly produces colorimeter, spectrophotometer, color density meter, gloss meter, color light box, color proof table, coating thickness gauge, iso test chart, etc.
Our Certificates:
ISO9001; CE; FCC; ROHS; TUV; SCM.
The parameters of test results are integrating with international standards. Our products are exported around the world. We can provide customization service which has been well received by customers.
Other products:
Warranty:
Silk Brand Color Meter / Colorimeter Price Manufactuer is under warranty for 12 months from the purchase date. Customers must provide warranty card and valid proof of purchase.
