ISO9001 Certificate Concrete Spraying Equipment KP25 800 Hydraulic Cylinder Moving Distance
Price:
negotiable
MOQ:
1 unit
Delivery Time:
15 working days
Brand:
POTENTIAL
Product Description
KP25 Concrete Spraying Equipment, wet shotcrete pump, without Manipulator, motor power, wireless remote control
Applications
Widely used in concrete spraying projects of small working sections, such as culvert, diversion tunnel of hydropower station, subway, mining and other underground projects.
Specifications
| 1 | Genenral parameter | Weight (kg) | 2150 | |
| Outside dimension(L×W×H)(mm) | 3800×1500×1600 | |||
| 2 | Pumping system | Theoretical pump capacity (m³/h) | 4～25 | |
| Filling height(mm) | ＜1200 | |||
| Max.aggregate size(mm) | ≤16 | |||
| Max. theory outlet pressure (MPa) | 7.5 | |||
| Pipe diameter(mm) | 100 | |||
| Concrete cylinder diameter(mm) | 140 | |||
| Concrete cylinder moving distance(mm) | 800 | |||
| Hydraulic cylinder(cylinder diameter/pole diameter)(mm) | 80/55 | |||
| Hydraulic cylinder moving distance(mm) | 800 | |||
| Hopper capacity(L) | 300 | |||
| Max.theoretical horizontal deliver distance(m) | 450 | |||
| Max.theoretical vertical deliver distance(m) | 160 | |||
| 3 | Motor | Rated Power(kW/rpm) | 45/1480 | |
| Rated voltage(V) | three-phase/380(optional) | |||
