Automatic Dry Powder 10-50kg Valve Bags Filling Machine Sand Packing Machine
Automatic Dry Powder 10-50kg Valve Bags Filling Machine Sand Packing Machine
Fair sand packing Introduction
Fair Sand Packaging Machine ( valve bag packing machine ) , the improved model of the latest development ,different from other factory production. We improve its most precise measurement sensing system, changed the way of lifting force sensor, the industry generally used, to the pressure sensing mode, making the packing machine life and accuracy greatly improved, Bag weight error from the original error of ± 0.5-1kg reach ± 0.25kg. Filling mouth also made design changes, adding a "gas returning nozzle" design, in the filling process the bag excess gas can be discharged, so that the filling process more smoothly.
|
Item |
FMP-01 valve bag packing machine |
||
|
Weighing Scope |
10~60kg, adjustable on panel. |
||
|
Discharge Port Qty. |
1 pic |
||
|
Capacity |
8-12 t/h |
||
|
Motor Power |
3kw |
||
|
Measuring accuracy |
±0.2-0.4％ |
||
|
Bag weight qualified rate |
>95% |
||
|
Weighing device |
Micro-computer |
||
|
Overall dimension(mm) |
1200*670*1200 |
||
|
Air Requirements |
0.4-0.8MPa ( dry compressed air) |
||
|
Application Environment |
Operating temperature |
0℃～50℃ |
|
|
|
Storage temperature |
-20℃～60℃ |
|
Overview
|
Type: Other |
Condition: New |
Application: Chemical, construction material, dry mix mortar, Coating and other industries |
|
Packaging Type: Bags, Stand-up Pouch, Other |
Packaging Material: cement, powder, mortar, fine particles and so on |
Automatic Grade: Automatic |
|
Driven Type: Electric |
Voltage: 380V/50HZ |
Power: 3KW |
|
Place of Origin: Henan, China (Mainland) |
Brand Name:Fair Machinery |
Model Number: FMP-01 |
|
Weight: 185kg |
Dimension(L*W*H): 1070x670x1030 |
Certification: CE ISO |
|
After-sales Service Provided: Engineers available to service machinery overseas |
Name: Valve mouth packaging sand |
Weighing Scope: 10~60kg, adjustable on panel. |
|
Discharge Port Qty.: 1 pic |
Capacity: 8-12 t/h |
Motor Power: 3kw |
|
Weighing device: Micro-computer |
Packing speed: 3-5s per bag |
Overall dimension(mm): 1070*670*1030 |
|
Air Requirements: 0.4-0.8MPa ( dry compressed air) |
Operating temperature: 0℃~50℃ |
|
Packaging & Delivery
Packaging Detail
Packaging details: wooden case packing;
Delivery detail: Shipped in 7-10 working days after payment
Delivery Time
SHIPPING IN 5 WORKING DAYS AFTER RECEIVING YOUR PAYMENT
Fair sand bagging machine Main Features
1. The Sand Packaging Machine with dust collector can link to external filter, it also reduces dust in the environment and available to the protection of operator and environment.
2. Fast packing speed, accuracy stability
3. Accurate weighing, stable performance, simple operation, good seal, reasonable structure, durable, small volume, light weight, convenient adjustment and maintenance, mechanical and electrical integration, save power. The machine can be used in packing both the cement powder and particulate material.
