Professional Energy-Saving Lacquer Mixer,Stone Finish Paint Blender , Stone-Like Paint Equipment
Professional Energy-Saving Lacquer Mixer,Stone Finish Paint Blender,Stone-Like Paint Equipment
Product Description
Stone-like paint, texture paint, sand paint, floor paint, rock paint, relief paint, rock chip paint, texturing paint, putty paste and other thick paste paint. The horizontal stone paint mixer adopts U-shaped appearance design, in which the double-layer spiral belt is used for mixing, and the screw rotation direction is different. When the main shaft rotates, one spiral belt transports the material from left to right, and the other spiral belt transports the material from right to left. The materials are stirred and mixed.
Advantages of spiral mixer machine
1. High stirring efficiency, small floor space. The spiral blade adopts special high – wear alloy.
2. The pan mixer adopts the reducer transmission; the rotation is stable, and the noise is low.
3.Feeding from top and discharging from bottom, which is reasonable structure.
4.The joint surfaces are tightly sealed and run smoothly.
Application of spiral mixer machine
The Horizontal Screw Belt Mixer is a new type, high efficiency mixing equipment, are widely used in mixing industry
Our company stone paint mixing machines is easy use and maintains and clean, small occupies, high efficient and long service life; Stone paint mixer machine is specialized in blending the resin emulsion with different gradations of sand particles.
Two discharge ports, fast and clean discharge, mixing screw belt with wall hanging function, mixing cylinder can be turned over, easy for material cleaning, etc.
2. Technical Parameters of spiral mixer machine
3. Main Features of spiral mixer machine
Horizontal mixer is rotated by a shaft that added a spiral blade, then adding water to mix while conveying dry ash and other powdery materials, so that the dry ash powder can be humidified equably, which makes the material being humidified do not run dry ash while the water drop can not oozed.
How work of fair spiral ribbon mixer
Ribbon mixer consist of a U-shaped horizontal trough and a specially fabricated ribbon agitator.
A ribbon agitator consists of a set of inner and outer helical blades. The outer ribbon moves materials toward the center of the trough,
and the inner ribbon moves the materials toward the outside of the trough. The ribbon also rotates at approx. 50rpm,
thus moving materials both radially and laterally to insure thorough blends in short cycle times.
Ribbon agitators are used for blends that will be between 40 and 70% of the rated capacity of the blender.
