10 - 60 Kg Valve Bag Filling Machine , Multi Purpose Packaging Machine Accurate Weighing
10 - 60 Kg Valve Bag Filling Machine , Multi Purpose Packaging Machine Accurate Weighing
Fair valve bag filling packaging machine is a powder weighing packaging machine specially designed for dry mortar, cement, chemical and other industries. It has the advantages of small size, strong function, high reliability, good adaptability, etc. It integrates weighing control and has unique anti-interference ability and can be used for a long time in harsh environments.
|
Type: Other |
Condition: New |
Application: Chemical, construction material, dry mix mortar, Coating and other industries |
|
Packaging Type: Bags, Stand-up Pouch, Other |
Packaging Material: cement, powder, mortar, fine particles and so on |
Automatic Grade: Automatic |
|
Driven Type: Electric |
Voltage: 380V/50HZ |
Power: 3KW |
|
Place of Origin: Henan, China (Mainland) |
Brand Name:Fair Machinery |
Model Number: FMP-01 |
|
Weight: 185kg |
Dimension(L*W*H): 1070x670x1030 |
Certification: CE ISO |
|
After-sales Service Provided: Engineers available to service machinery overseas |
Name: Valve mouth packaging sand |
Weighing Scope: 10~60kg, adjustable on panel. |
|
Discharge Port Qty.: 1 pic |
Capacity: 8-12 t/h |
Motor Power: 3kw |
|
Weighing device: Micro-computer |
Packing speed: 3-5s per bag |
Overall dimension(mm): 1070*670*1030 |
|
Air Requirements: 0.4-0.8MPa ( dry compressed air) |
Operating temperature: 0℃~50℃ |
|
Packaging & Delivery
Packaging Detail
Packaging details: wooden case packing;
Delivery detail: Shipped in 7-10 working days after payment
Delivery Time
SHIPPING IN 5 WORKING DAYS AFTER RECEIVING YOUR PAYMENT
Application of Sand filling machine :
Masonry mortar
1. Thin and smooth wall mortar.
2. Hand-plastering screeding mortar.
3. Colored coating mortar.
4. Water-proof mortar.
5. Plaster powder.
6. Wall plastering mortar.
7. Ceramic tile adhesive mortar.
8. Self-leveling mortar.
9. Heat-preservation mortar.
10. Repairing mortar.
11. Gap filler.
This kind of packing machine is widely used for filling and packing the dry powder materials, like: fly ash, coal powder, lime powder, mortar,cement and other materials.
The features of Fair bag filling machine
1.Automatic weighing and packing system, weighing accurately;
2.Small size and light quality, moving and installation conveniently;
3.Steady performance, easy to operate and maintenance;
4.High automation, labor-saving and increase efficiency.
Working Principle of Automatic Valve filling Machine
The automatic weighing and packing machine receives the weight of analog signal by gauge and sensor and convert to figure signal, to control contactor and solenoid vale by relay switching signal to achieve the motor rotation stop and air cylinder operation. The discharge principle is use high-speed rotation of the power head paddles make the material quickly set aside from the discharge port, the internal air blown inside the power head form a high pressure and puff away materials to help paddles disperse the
