50 Kg Cement Bag Packing Machine / Valve Port Packing Machine For Powder Material
50 Kg Cement Bag Packing Machine / Valve Port Packing Machine For Powder Material
Product advantages:
1 The measuring of this machine with two type : machinery scale and computer scale. weighing accurate and stable performance, simple operation.
2 Good sealing, reasonable structure, durable.
3 Small volume, light weight, easy adjustment and maintenance
4 Electromechanical integrated, managing electric energy: this machine does not use air compressor and electromagnetic valve and pneumatic components, through the machine, electricity, leverage the principle of a linkage, can realize the automatic packing pressure, loosen, of the gate closed and off bag etc..
5 Extensive use: the machine is not only used for cement packing, can also be used to other good liquidity powder, granule materials packaging.
Overview
|
Type: Other |
Condition: New |
Application: Chemical, construction material, dry mix mortar, Coating and other industries |
|
Packaging Type: Bags, Stand-up Pouch, Other |
Packaging Material: cement, powder, mortar, fine particles and so on |
Automatic Grade: Automatic |
|
Driven Type: Electric |
Voltage: 220/380V/50HZ |
Power: 3KW |
|
Place of Origin: Henan, China (Mainland) |
Brand Name:Fair Machinery |
Model Number: FMP-01 |
|
Weight: 185kg |
Dimension(L*W*H): 1070x670x1030 |
Certification: CE ISO |
|
After-sales Service Provided: Engineers available to service machinery overseas |
Name: Valve mouth packaging sand |
Weighing Scope: 10~60kg, adjustable on panel. |
|
Discharge Port Qty.: 1 pic |
Capacity: 8-12 t/h |
Motor Power: 3kw |
|
Weighing device: Micro-computer |
Packing speed: 3-5s per bag |
Overall dimension(mm): 1070*670*1030 |
|
Air Requirements: 0.4-0.8MPa ( dry compressed air) |
Operating temperature: 0℃~50℃ |
|
Product Description
Our valve port packing machine (valve bag packing machine), the improved model of the latest development ,different from other factory production.
We improve its most precise measurement sensing system, changed the way of lifting force sensor,
the industry generally used, to the pressure sensing mode, making the packing machine life and accuracy greatly improved,
Bag weight error from the original error of ± 0.5-1kg reach ± 0.25kg.
Filling mouth also made design changes, adding a "gas returning nozzle" design, in the filling process the bag excess gas can be discharged,
so that the filling process more smoothly.
|
Item |
FMP-01 valve bag packing machine |
||
|
Weighing Scope |
10~60kg, adjustable on panel. |
||
|
Discharge Port Qty. |
1 pic |
||
|
Capacity |
8-12 t/h |
||
|
Motor Power |
3kw |
||
|
Measuring accuracy |
±0.2-0.4％ |
||
|
Bag weight qualified rate |
>95% |
||
|
Weighing device |
Micro-computer |
||
|
Overall dimension(mm) |
1200*670*1200 |
||
|
Air Requirements |
0.4-0.8MPa ( dry compressed air) |
||
|
Application Environment |
Operating temperature |
0℃～50℃ |
|
|
|
Storage temperature |
-20℃～60℃ |
|
Main Features
1.valve port packing machine with dust collector can link to external filter, it also reduces dust in the environment and available to the protection of operator and environment.
2. Fast packing speed, accuracy stability
3. Accurate weighing, stable performance, simple operation, good seal, reasonable structure, durable, small volume, light weight, convenient adjustment and maintenance, mechanical and electrical integration, save power. The machine can be used in packing both the cement powder and particulate material.
