Revolving Motor / Needle Winding Machine 1200rpm Brushless Dc New Energy
1200RPM Brushless DC New Energy Revolving Motor Stator Needle Winding Machine WIND-T1000
(1) Application
High Efficiency Needle winding for BLDC Stators
Small Pump Motor, New Energy Automobile Car Revolving Motor,
DC Brushless Motor,New Energy Car Spinning Stator Winding Machine
(2) Advantages
Dedicated Winder for small motor with thin wire, crazy fast 1000~1200RPM,
Four station BLDC Stator winding machine WIND-T1000 wind the brushless DC motor stator
with four station to improve efficiency!
(3) Parameter
Wire diameter:0.01 to 0.70 mm (suitable for thin wire and small stator)
Stator ID: 12 to 130 mm
Stack height: 5 to 30mm
Winding motor: Servo motor Panasonic 3000W 1pc
Arraying motor: Servo motor Panasonic 2000W 2pcs
Indexing motor; Servo motor Panasonic 750W 2pcs
Speed: 300 to 600 RPM
Air pressure:5~7kg/square centi-meter
Power:AC380V 50/60Hz
Weight: about 480kgs
Dimension: 1800(L)x850(W)x1600(H)mm
Below samples are needed for machine manufacturing and commissioning:
1. Stator stack 5pcs without winding
2. Wound stator 1pc
3. Copper wire 1 roll enough for winding 15pcs stators
Please click below video to watch machine winding for 14 pole new energy vehicle rotary motor
