240 W 36 V Constant Voltage LED Power Supply Waterproof For LED Lighting 90 - 305 VAC
Dimensions: 244.2*68*38.8mm
Keywords: Meanwell (MW) LED Power Supply
Packaging Details: 12pcs per carton / CBM:0.8 / GW:14.8KG
Delivery Time : 3-14DAYS
- Metal housing with class I design
- IP67 / IP65 rating for indoor or outdoor installations
- Function options : output adjustable via potentiometer;
- Typical lifetime > 62000 hours
- 7 years warranty
- LED high-bay lighting
- Parking space lighting
- LED fishing lamp
- LED greenhouse lighting
- Type “HL” for use in Class, Division 2 Ihazardous (Classified) location.
| MODEL | HLG-240H-12 | HLG-240H-15 | HLG-240H-20 | HLG-240H-24 | HLG-240H-30 | HLG-240H-36 | HLG-240H-42 | HLG-240H-48 | HLG-240H-54 | |
| OUTPUT | DC VOLTAGE | 12V | 15V | 20V | 24V | 30V | 36V | 42V | 48V | 54V |
| RATED CURRENT | 16A | 15A | 12A | 10A | 8A | 6.7A | 5.72A | 5A | 4.45A | |
| RATED POWER | 192W | 225W | 240W | 240W | 240W | 241.2W | 240.24W | 240W | 240.3W | |
| INPUT | VOLTAGE RANGE | 90-305VAC 127-431VDC | ||||||||
| FREQUENCY RANGE | 47-63Hz | |||||||||
| EFFICIENCY(Typ.) | 90% | 90% | 91.50% | 92.50% | 92.50% | 92.50% | 92.50% | 93% | 93.50% | |
| AC CURRENT | 4A /115VAC 2A/230VAC 1.2A/277VAC | |||||||||
Q1. Can I have a sample order for Meanwell (MW) LED Power Supply HLG-240H-36?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A:Sample needs 5-7 days, mass production time needs 2-3 weeks. The actual time is up to the quantity.
Q3. Do you have any MOQ limit for Meanwell (MW) LED Power Supply HLG-240H-36 order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for Meanwell (MW) LED Power Supply HLG-240H-36?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to use my own package?
A: Yes.Normally we offer the white box without any printing.If you have the deisgn of box,we can help you produce in China and pack it.
