High Speed 20 PCS Heads SMT Pick And Place Machine 380 VAC AC 50HZ For SKD Making
20 PCS heads LED DOB SKD making machine SMT pick and place machine
Machine main features
- Adopt High speed multi modular head, apply to ultra small chip 0201~40*40 mm large chip, wider component range;
- Brand new flight vision camera: Improve recognition performance, size up to 40*40 mm, apply to BGA or CSP etc;
- Vacuum sensing device: Each placement head with independent detection function, which improves the stability of the equipment and the reliability of the product;
- Ultra high speed capability: Adopt high-end magnetic linear motor, servo system and multi function modular head, the capacity increased by 25% compared with traditional machine, optimum speed reach 80000 CPH;
- Combine high accuracy Mark recognition camera with fixed flight vision camera, ensure placement accuracy;
- Off-line programming, save time of changeover cycle;
- Software AI intelligent learning function and automatic optimization function.
- Two gantry, 10 spindles*2 Gantry, total 20 spindles;
- Flexible PCB handling capabilities, double rail, both gantry can mount the same large PCB at the same time, realizing flexible production.
Machine main parameter
| Model | YT-202S |
| PCB size |
Max size: 500*450 mm(Single side) 500*300 mm(Double side) Min size: 50*50 mm |
| PCB thickness | 0.5-4.5 mm |
| Production management MES system | Customized (Option) |
| Off-line programming | Available |
| Camera |
Head flight vision recognition component Vision alignment + Mark correction |
| Repeat precision | ±0.02 mm |
| Mounting height | ≦15 mm |
| Optimal speed | 80000 CPH |
| Component range | Min 0201~40*40 tape reel packages and IC tray feeder etc. |
| No.of heads |
Double side: 20 pcs Single side:10 pcs |
| X,Y,Z, Axis drive way | High-end magnetic linear motor + Servo motor |
Machine application
Market
Our products had exported to more than 30 countries and regions, including South Korea, India, Vietnam, Tunisia, Egypt,Turkey, Russia, Brazil etc. And here are some of our big customers:
SURYA, POLYCAB, FIEM, RK, GK, TECHNO LED, CALCOM, ACK , KENDAL, RangDong, UNISTAR, and so on.
Our Exhibitions
Our company has participated in various exhibitions in foreign countries, including India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc.
Related machine
We can provide a whole SMT production line,led light production line:
1.Pick and place machine
2. Loader machine
3. Conveyor machine
4. Stencil printer machine
5. Reflow oven machine
6. Unloader machine
7. Solder paste mixer
8. Roll to roll led strip light assembly machine
FAQ
Q.How can I make inspection when something wrong with the machine?
A. Well, the inspection is taken by our professional engineer to check and modulate the machine, if you counter any problem of our machine please contact us, and we will arrange our engineer to solve it.
Q. How long is the machine maintenance period, whether it is free?
A. The maintenance period of our machine is 1 year and its free for our clients, after the maintenance period we will arrange our engineers to check and test the machine one or two times a year freely.
