30 Feeders Smt Assembly Machine High Speed Circuit Board Energy Bulbs Led Equipment
high accuracy and high-speed circuit board energy bulbs led equipment multifunctional pick and place machine HT-E5S
Features:
1) Single module magnetic linear motor multifunctional pick and place machine.
2) Mounting components:LED,capacitors,resistors,IC,shaped components,etc.
3) Component:Min.size 0402 Max.height 36mm.
4) Application:Power driver.electric board.lens.linear bulb.household appliance etc.
Application:
Technical parameter
| Dimension | Length | 1650MM |
| Width | 1200MM | |
| Height | 1570MM | |
| Total Weight | 1200KG | |
PCB |
PCB Size | Max:500*350mm Min:100*100mm |
| PCB Thickness | 0.5-3mm | |
| PCB Clamping | Electric clamping + Adjustable pressure pneumatic | |
| Mounting Mode | group picking and separate placing,separate picking and separate placing. | |
| Vision System | No. of Camera |
2 set of imported camera |
| Vision for the Flight Identification,Mark correction. | ||
| Mounting Precision | ±0.02mm Chip | |
| Mounting Height | <36MM | |
| Mounting Speed | 40000CPH | |
| Components:Max:36mm,Min:LED 0402 | LED,resistor,capacitors,shaped components,etc. | |
| Components Space | 0.2mm | |
| Feeding System | No. of Feeders | 30PCS |
| No. of Nozzles | Single Heads:8pcs Nozzles | |
| Feeder Style | Use Electric Feeders | |
| Non-stop refueling function | ||
| The automatic optimization function | ||
| X,Y ,Z Axis Driving | High-end magnetic linear motor + Servo Motor | |
| OS | Software | R&D independently |
| Display | LED Display | |
| Input Device | Keyboard,Mouse | |
| Power | 380AC 50Hz | |
| Power Consumption | 4KW | |
| Operating Environment | 23°C±3°C | |
| Transmission Speed | >500mm/sec | |
| Transmission Direction | Single(left→right or right→left) | |
| Transmission Mode | Online Drive | |
| Air Pressure | >5.0KG/cm² | |
| Motion control card module | Independent research and development by ETON | |
| Electrical control | Independent research and development by ETON |
Company Introduction:
ShenZhen ETON Automation Equipment Co.,LTD.is a leading manufacturer of automatic high-speed pick and place machine focusing on “High efficiency Low consumption”in the world,meanwhile ETON also the largest high-tech manufacturer in Chine with strong capability of design,R&D,manufacturing,sales&service,and rates as “Shenzhen high-tech enterprise”“China high-tech enterprise”“Shenzhen TOP Brand”“2015LED Technology Innovation Award”“The 4th China LED First Innovation Award”“Industry Special Contribution Award”“Double soft enterprise”etc.
Clients:
Our service:
1. Quick response within 24 hours;
2. Offer free spare parts and service within one year of warranty .
3. Technology Support :We will send our engineer to your factory to install machine and training freely ; Provide Demo operation video for training show you the operation .
4. Good and professional after-sales service.
Packing Method:
Vacuum wooden package
Delivery Time:
15~30 Days
