Pneumatic 4mm PCB Pick And Place Machine 170000CPH
Automation vision pneumatic pick and place high-quality LED mounting machine
Product description
Dual purpose professional high speed mounter, 2~4 type of capacity reach 150000CPH
Vision alignment, Mark correction
Components: LED 3014/3020/3528/5050 and capacitors, resistors, bridge rectifiers, etc
Application: flexible strip, LED tube, panel light, etc
Features
Apply to the 0.6m, 0.9m,1.2m rigid PCB and 0.5m,1m LED flexible strip. producing with 2~4 types of materials with high capacity ,available for board with any proportion of LED chip and resistors.
Two mounting modules ,18 nozzles for each mounting part, part A or B can be mounted separately or synchronously.
Exclusive patent technology :group to take and group to mount.
technical parameter
| HT-F7S pick and place machine | ||
| Dimension | Length* Width* Height | 2700mm*2450mm *1530mm |
| Total weight | 1400kg | |
| PCB | PCB Size | Max:1200*330mm Min:50*50mm |
| PCB Thickness | 0.5-5mm | |
| PCB Clamping | Adjustable pressure pneumatic | |
| Mounting mode | Group to take and group to mount | |
| O.S. | System | Windows 7 |
| Software | R&D independently | |
| Display | Touch screen monitor | |
| Vision System | No. of camera | 5PCS(Digital camera) |
| Vision alignment, Mark correction | ||
| Mounting precision | +0.02mm( repeat precision) | |
| Mounting speed | 150000-170000CPH | |
| Components | LED3014/3020/3528/5050, capacitors, resistor, bridge rectifiers, etc | |
| No. of feeders station | 68PCS | |
| No. of nozzles | 34PCS | |
| XYZ Axis drive way | High-end magnetic linear motor + servo motor | |
| Feeding way | Electric feeder with double motor | |
