34 Heads SMT Mounting Machine High Capacity Flexible Strip SIRA 180000CPH
High capacity for unlimited length of flexible strip with 34 pcs of heads pick and place machine
Product introduction
High speed mounter for unlimited length of flexible strip, capacity reach 180000 CPH, producing 2-4 types of materials with 34 PCS of head, available for 5M, 50M or any length of flexible strip and roll to roll.
Features:
- Producing 2-4 types of materials with high capacity, available for 5M, 50M or any length of flexible strip and roll to roll.
- Two module 17 nozzles for each mounting part, part A or part B can be mounted separately or synchronously.
- Calibration automatically, high precision, available for RGB.
- Exclusive patent technology: Group to pick and group to mount.
IPC9580 Capacity: 150000- 180000 CPH
Patent number: ZL2011 2 0237740.9ZL2011 2 0334606.0ZL 2012 20178869.1ZL 2012 2 0415505.0ZL2012 2 0415044.7ZL2012 2 0415356.8ZL2012 20415061.0
Machine parameter
| Model | HT-T7S |
| Dimension | 3100*2300*1550mm |
| Total weight | 1700kg |
| PCB length width | 250mm*any length |
| PCB thickness | 0.5-1.5mm |
| PCB clamping | Vacuum adsorption, cylinder splint, adjustable track width |
| Mounting mode | Group picking and group placing |
| Mounting precision | ±0.02mm |
| Mounting speed | 150000-180000CPH |
| No. of feeders station | 68PCS |
| No. of head | 34PCS |
Company profile
SHENZHEN ETON AUTOMATION EQUIPMENT CO.,LTD
Founded in 2011, an excellent company for SMT mounter machine, ETON obtained 9 invention patents, 112 practical patents, 12 software copyrights of intellectual property technologies, to be a leading manufacturer of SMT trade.
Our Exhibition
Our company has paticipated in various exhibitions in foreign countries, including India Mumbai Exhibition, India Delhi Exhibition, Egypt Exhibition, Turkey Exhibition, Pakistan Exhibition, etc.
Our services
FAQ
Q1. Can you arrange your engineers to our country for a training of the machine?
A1. Yes, our clients enjoy a free traning for the machine as installation, maintenance etc.
Q2.How can I get an optimal line for our product?
A2. As the needs of the whole line solution, we will provide our professional suggestion and a whole line production for our clients, as to provide a suitable plant layout.
Q3. What is your usual payment term?
A3. We usually use T//T as the payment term.
Q4.
What is your actual speed of your products?
A4. For the actual speed of the machine which is constrained by many factors, that related to the number of the components, the time to send PCB board and receive the board, etc. And is decide for the actual products and needs.
Q5. How long is the machine maintenance period, whether it is free?
A5. The maintenance period of our machine is 1 year and its free for our clients.
