ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes
Chinese Supplier EB ASME SB-751 Inconel 600 Seamless Pipes and Welded Tubes Price
Inconel 600 is a nickel-chromium alloy used for applications that require corrosion and high temperature resistance. This nickel alloy was designed for service temperatures from cryogenic to elevated temperatures in the range of 2000° F. It is non-magnetic,has excellent mechanical properties, and presents the desirable combination of high strength and good weldability under a wide range of temperatures. The high nickel content in Inconel 600 enables it to retain considerable resistance under reducing conditions, makes it resistant to corrosion by a number of organic and inorganic compounds, gives it excellent resistance to chloride-ion stress-corrosion cracking and also provides excellent resistance to alkaline solutions. Typical applications of this nickel alloy include the chemical, pulp and paper, aerospace, nuclear engineering and heat treating industries.
In what form is Inconel 600 Available?
* Sheet
* Plate
* Bar
* Pipe & Tube (welded & seamless)
* Fittings (i.e. flanges, slip-ons, blinds, weld-necks, lapjoints, long welding necks, socket welds, elbows, tees, stub-ends,returns, caps, crosses, reducers, and pipe nipples)
* Wire
What are the characteristics of Inconel 600?
* Resistant to a wide range of corrosive media.
* Virtually immune to chlorine ion stress corrosion cracking
* Non-magnetic
* Excellent mechanical properties
* High strength and good weldability under a wide range of temperatures
* Chemical industry
* Aerospace
* Heat treating industry
* Pulp and paper industry
* Food processing
* Nuclear Engineering
* Gas turbine components
Fabrication with Inconel 600
Alloy 600 can be both hot formed and cold formed using typical processes. Hot working should be performed between 1600° F and 2250° F avoiding any work between1200-1600° F because the ductility decreases in this temperature range. Welding Alloy 600 can be achieved via shielded metal-arc welding, TIG, and MIG.
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
|
|
|
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665 |
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/925/926;
|
|
|
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60;
|
|
|
Nimonic: Nimonic 75/80A/90/A263 ;
|
|
Specification |
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
|
Standard
|
GB,AISI,ASTM,DIN,EN,SUS,UNS etc
|
|
Inspection
|
ISO,SGS,BV and so on.
|
|
Application |
High temperature components such as turbine blades, guide vanes, turbine disks,
high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines |
|
Packaging |
1. cases packed in wooden cases
2. paper packaging 3. plastic packing 4. foam packaging Packaging according to customer requirements or products |
|
Delivery
|
7-25days orAccording to the product
|
|
Chemical Composition:
|
|||||||||
|
Composition (%)
|
C
|
Cr
|
Mn
|
Si
|
Fe
|
Cu
|
S
|
P
|
Ni
|
|
Inconel 600
|
≤0.15
|
14.0-17.0
|
≤1.00
|
≤0.50
|
6.0-10.0
|
≤0.50
|
≤0.03
|
≤0.03
|
Bal.
|
|
ASTM Specifications:
|
|||||||
|
Pipe Smls
|
Pipe Welded
|
Tube Smls
|
Tube Welded
|
Sheet/Plate
|
Bar
|
Forging
|
Fitting
|
|
B167
|
B517
|
B163
|
B516
|
B168
|
B166
|
B564
|
B366
|
|
Product Form
|
Condition
|
Tensile (ksi)
|
.2% Yield (ksi)
|
Elongation (%)
|
Hardness
|
|
Rod & Bar
|
Cold-Drawn
|
80-100
|
25-50
|
35-55
|
65-85
|
|
Rod & Bar
|
Hot-Finished
|
80-100
|
30-50
|
35-55
|
65-85
|
|
Tube & Pipe
|
Hot-Finished
|
75-100
|
25-50
|
35*55
|
- |
|
Tube & Pipe
|
Cold-Drawn
|
80-100
|
25-50
|
35-55
|
88 Max
|
|
Plate
|
Hot-Rolled
|
80-105
|
30-50
|
35-55
|
65-85
|
|
Sheet
|
Cold-Drawn
|
80-100
|
30-45
|
35-55
|
88 Max
|
Product Details:
