Weld Oil Storage EPS Roof Q235b Prefab Steel Workshop
Waterproof steel structure workshop for grain and oil storage
Prefabricated metal structure workshop
The prefabricated metal structure workshop consists of a plane frame structure. The main structure includes steel columns, steel roof beams, and wind-resistant columns. Steel grade Q345B, yield strength is 345Mpa. The secondary structure includes roof supports, X-shaped cross-support tie rods, steel rods, roof purlins, and wall enclosures. Steel grade Q235B, yield strength 235Mpa.
| Description | ||
| Main Components | Base | Concrete and steel foundation anchor bolts |
| Main frame | Hot Rolled or Welded H-Section Steel | |
| Material | Q235B, Q345B or others as per client's requests | |
| Purlin | C/Z purlin: Size from C120~C320, Z100~Z320 | |
| Bracing | X-type or other type, angle or round pipe | |
| Bolt | Plain or High-strength bolt | |
| Roof & wall | EPS / Rockwool / PU Sandwich panel or colored steel sheet | |
| Door | Electric flat door | |
| Window | Aluminum or PVC window | |
| Surface Coating | Anti-rust Paint or Hot Dip Galvanize | |
| Sheet | 0.3-0.8mm galvanized or color coated steel sheet | |
| Accessories | Translucent skylight sheet, Ventilators, etc. | |
| PVC Down pipe, Galvanized / SS304 gutter, etc. | ||
| Usages | 1. Workshop, warehouse, plant, storage | |
| 2. Steel web frame structure | ||
| 3. High rise building project | ||
| 4. Others steel structure buildings | ||
| Packing | Main steel frame without packing load in 40' OT or 40'HQ | |
| Roof and wall panel load in 40' HQ | ||
| Drawing | By client or RPIC | |
| Design Parameters | If need design from Honkae, please supply following parameters: | |
| 1) Length, width, eave height, roof apex | ||
| 2) Live Load, Wind Speed, Seismic Load, Snow Load etc. | ||
| 4) Quantity and sizes for doors and windows | ||
| 5) Other information if necessary | ||
Advantages of prefabricated metal structure workshop:
1. The wall panels and roof panels of the fixed metal structure workshop overlap when they are fixed together. Leave no openings so that the building can be isolated from the outside world. It helps to make the building warm in winter and cool in summer, thereby saving energy costs.
2. The prefabricated metal structure workshop is more durable and coated with anti-rust paint. Since all drilling, cutting and welding are done before the steel structure is delivered to the construction site for assembly, they are also cheaper and faster to build.
3. The prefabricated metal structure workshop is composed of a main engine, which connects H-shaped steel, C-shaped Purline, support system, beams and other steel components. Roofs and walls use various panels and other components (such as doors and windows). The prefabricated metal structure workshop has the advantages of large span, high strength, light weight, low cost, temperature protection, energy saving, beautiful appearance, short construction time, good insulation effect, long service life, space saving, and good seismic performance. Performance-flexible layout, etc.
4. The main load-bearing component of the prefabricated metal structure workshop is the steel structure, including steel columns, steel beams, walls and roof support systems. In China, the main structure uses Q345 steel, steel strength: 345Mpa, Pur bar and support system Q235 steel. Steel strength: 235Mpa
The prefabricated metal structure workshop can meet the needs of various projects from commercial (car shed, exhibition hall) to agriculture (metal warehouse, warehouse shed) to industry (factory, equipment warehouse).
