Wood And Plastic Tray Waste Shredder Machine With Double / Four Shaft Design
Wood and plastic tray Shredder Large forklift pallet double/ four shaft crusher
According the capacity and how hard the plastic and wood is ,we will supply double shaft shredder and four shaft shredder.
Equipment features:
- Thick and heavy rotator blades, high crushing power, all blade tools are made of alloy tool steel and wear-resistant die steel, with long service life.
- Frame plate is thick, resistant to high torque, strong enough.
- Setting start, stop, reverse and overload automatic reverse control.
- Equipment with low speed, high torque, low noise, dust can meet the environmental standards.
- Easy to adjust, low maintenance cost, economical and durable
- Blade tool thickness and number of jaws can be changed according to different materials
Main Technical Parameter of double axis plastic shredder plant :
| Model | Power(KW) | Number of revolving knife |
thickness of knife (mm) |
Diameter of knife (mm) |
Number of knife |
Dimension of crushing chamber (mm) |
Output (kg/h) |
| S2-600 | 11 | 12 | 50 | 280 | 5 | 600*550 | 300-800 |
| S2-600 | 15 | 12 | 50 | 280 | 5 | 600*550 | 300-800 |
| S2-800 | 22 | 16 | 50 | 300 | 5 | 800*600 | 500-1500 |
| S2-800 | 37 | 16 | 50 | 300 | 5 | 800*600 | 500-1500 |
| S2-1000 | 2*30 | 20 | 50 | 350 | 5 | 1000*700 | 1000-2000 |
| S2-1200 | 2*30 | 24 | 50 | 400 | 5 | 1200*800 | 1500-2500 |
| S2-1600 | 2*37 | 22 | 70 | 450 | 5 | 1600*900 |
2000-3000 |
More Photos:
What will we do and final make?
We also can do Single shaft shredder and Crusher one unit
If you want to know more information about single shaft shredder,double shaft shredder,four shaft shredder,welcome to contact with us.
