SUS304 Material PET Bottles Washing Plant Used Plastic PET Flakes Washing Line

Description:

Stplas series plastic recycling machine will be used to recycle pet bottle, water bottle, Sprite bottle, cola bottle, juice bottle, pet sheet, pet packing container and so on.Used plastic PET flakes washing line includes label remover machine, grinder crusher machine, sorting equipment, hot washing

tank, friction washing machine, float washing tank, hot air dryer system, zig zag label separator, air silo etc.

Main Machines:

1. Trommel Separator – A large, slow rotating machine used to remove small pieces of contamination. At the core of the trommel separator is a large mesh screen tunnel that rotates between 6-10 rotations per minute. The holes on this tunnel are small enough so the PET bottles will not fall through, however, large enough so small particles of contamination will.
2. Label Separator – The stream of plastic leaving the granulator is composed of PET flakes, paper and PP/PE/PVC film from the labels, and PP/PE rigid plastics from the bottle caps. This mixed stream is now ready to be sorted. The first step is the label separator where a column of pressured air blows away the lighter paper and plastic film into a separate collection tank.
3. Floating Tank – A large tank of water used to separate materials that sink from those that float. This is the final separation equipment in our PET bottle washing line that effectively removes the left over plastic films from labels and PP/PE bottles caps. As both the labels and bottle caps float in water, the sinking PET flakes can easily be removed to be further processed in the next piece of equipment.
4. Steam Washer – Similar to a washing machine in nature, this stream of PET flakes are washed using boiling hot water which sterilizes and further gets rid of contaminants such as glues (from the labels being glued on), grease/oils, and difficult to remove left-overs (beverage/foods) from the equation.
5. Silo – A large storage tank for the clean, dry PET flakes.

2000kg/h Parameter:

More Machine Photos:

After-Sales Service:

1. Engineers available to service machinery overseas.
2. We supply below necessary documents with the machine:
a. Machine layout.
b. Electricity diagram
c. Machine certificate
d. General manual book/maintenance book
3. After one year guarantee, the seller provides payable spare parts and technician's visiting maintenance service
